Outdoor RGB P20 live large stadium led display screen, football stadium perimeter led screen display

Outdoor RGB P20 live large stadium led display screen, football stadium perimeter led screen display   Product Description

Module: BESD-OFP20		Pixel type	Optional Real pixel/Virtual pixel
Pixel pitch	20mm	refresh frequency	2000HZ
Module Size	320mm×160mm	Horizontal View Angel	> 110 degree
Module Pixel	16×8	Working Environment	Temp:-20°c~+60°c humidity: 10%-90%
lattice density	2500dots/sq.m	Working voltage	AC100~120V AC 220~240V
Pixel form( Optional)	1Red, 1Green, 1Blue	Life time	100000 hours
The optimum viewing distance	20mm	Gray scale	Display colors ≥16.7M ;12 bit/color
Cabinet dimension	1280X960mm	Color display	1.07 billion
Cabinet resolution	64x48dots	Brightness	7000cd/sq.m
Cabinet weight	60 kg	Blind LED lamp rate	<0.0001
Drive mode	Constant current; static scan	Waterproof Class	IP65
Max power consumption	850W/sq.m	Warranty	2 Year

      Features Main features,Function Introduction 1. Designed according to the clients' standards. 2. Usage: Outdoor/Indoor Sports Perimeter,football stadium,basketball stadium,soccer stadium etc. 3. Waterproof: IP65 front,IP43 rear,the system can stand all weather condition. 4. High luminance and uniformity,wide view angle and various content show. 5. Iterms: BESD-OFP10,BESD-OFP12,BESD-OFP12.5,BESD-OFP16,BESD-OFP20,BESD-OFP25 etc.     Construction introduction 1. Special brackets installed at the back side of the cabinet is used for adjusting the gradient of the display,meanwhile it is easy to take down. 2. Strong side lockers keep two adjacent cabinets tight . 3. With fold and unfold block and tackle designed,easy for mounting and dismantling. 4. Soft,replaceable and impact-resistant covers protect leds from damaged and players from injury.     Soft Sheter 1. Protect the player from injury then the player hits the display. 2. Protect LEDs from damaged when the ball impacts the dispaly. 3. Easily replace. 4. Soft pad on the top of cabinet ,and easily to be removed when the cabinets will be assembled to video wall.     Two standards 1. Can be adjusted to different angles . 2. Easy to fold the two stands up to the flute,saving much space of store. 3. Special design can avoid the cabinet falling forward.     More unique designs in details  1. Power & net cable connector 2. High IP grade 3. Power cable connector with cover 4. Easily to plug in and out .     Products Photoes                       Trade Terms 1.Payment:T/T,40% deposits  ,  balance to be paid before dleiverying
2.Shipping freight are quoted under your requests
3.Shipping port: Shenzhen, Mainland China
4.MOQ:1sqm Packaging & Shipping 1. Packing:Plywood Cases, Corrugated Cartons or Flight Cases
2. Lead time: 20-25 working days;
3. Guarantee: One year's guarantee, with limited free part repair or replacement.
4. After Service: Free long-distance trouble shooting via telephone, email or video chatting; On-site technical support and installation is available upon customer's request.   Plywood Case:     Flight Case:       Main Products (1)Outdoor fix installation led screen:P6,P8,P10,P12,P14,P16,P20,P25 etc. (2)Indoor fix installation led screen:P3,P4,P5,P6,P7.62,P8,P10 etc (3)Outdoor rental led screen:P5,P6,P8,P10,P12,P14,P16,P20,P25 etc. (4)Indoor rental led screen:P2.5,P3,P4,P5,P6,P7.62,P8etc (5)Outdoor and indoor Perimeter LED Screen:P6,P7.62,P16,P20 etc (6)LED Curtain:P31.25,P37.5,P40 etc (7)LED Curve or Round,Column LED Screen: P6,P7.62,P8,P10, P12,P14,P16,P20,P25 (8)Dance floor led screen (9)Stage led screen  (10)Single color or dual color for text and graphic Company Information Developing history: From 1996, SHENZHEN BESD LED CO.,LTD. Previous name Xinhongxiang Optoelectronics (shenzhen) Co.,Ltd, mainly involved in LED encapsulation and LED Display.,led lamps , led lights . Since 2010, owe to enlarge the company scale and build up self-owned brand, Rename to Shenzhen BESDLED Co.,LTD, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products. Comparing with many of LED Manufactures, BESDLED owns the following advantages to be your best choice for long term cooperation partner.   1, Fully automatic production lines  BESDLED owns the entire LED manufacturing line, encapsulate original Semiconductor to LED chip, then assemble to led displayand led lighting products.   2, Advanced production equipment   SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP led, Spectrum and Color Separation Machine, LED oven,Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. are equipped for our LED Product production.   3, Many Certification approved to clear up the trade barriers   CE, FCC, UL, RoHS, CCC,ISO9001:2000 etc are obtained.         FAQ 1. How can I place an order? Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /phone, in case of any delays.   2. What kind of display we provide? We have indoor/outdoor/led curtain/mobile LED /rental LED display /LED stage/LED DanceFloor/Irregular LED display for you choose.   3. What about the lead time for order ? Always: 3-20 days, as your order quantity, Sometimes we have stock, can delivery within 3 days   4.How about the warranty ? We have 1-3 years warranty and lifelong maintenance   5. What is your terms of delivery? We accept EXW, FOB, CFR, CIF, DDU, DDP, etc. You can choose the one which is the most convenient or cost effective for you.   6. Is it OK to print my logo on led display product?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample. Warmly welcomed to contact us and visit our factory!
