Full color xxx video free movie China p20 outdoor RGB led sign Shenzhen led screen factory price Product Description 1,Specification
Module:P25 DIP, Chip size:R:12Mil; G&B:13X13Mil | LED Assembly Type | DIP546 |
Pixel Pitch | 25mm | Refresh frequency | 480Hz |
Module Size | 200x200mm | View Angle | 1100/500 |
Module resolution | 8x8pixel | Working Environment | Temp:-20°C~60°C, Humidity:10%~90% |
Dot density | 1600pixel/sqm | Working Voltage | AC:100V~120V AC:220~240V |
Pixel configuration | 2R1G1B | Lifetime | 100,000Hours |
The best view distance | 25-200M | Gray Scale | 10bit/color |
Cabinet dimension | 1000mmx1000mm(Optional) | Color Display | 1.07Billion |
Cabinet resolution | 40X40 | Brightness | ≥5000nit |
Cabinet weight | 55KG/sqm | MITBF | 0.00001 |
Drive mode | Constant current, Static Drive | IP | Front:IP65 Rear:IP54 |
Max Power Consumption) | 600W/sqm | Warranty | 2 year |
LED Parameter | R:d(625-630nm) R:IV(400-450mcd) | G:d(522.5-525nm) G:IV(1800-2200mcd) | B:d(467.5-470nm) B:IV(350-400mcd) |
Image adjustment | Brightness, contrast, tone, color range etc |
Image processing | Video denoising, rapid motion compensation, edge sharpening, edge smoothing, color coordinate conversation&control , grey scale transformation etc |
Brightness uniformity | Ratio of min pixel brightness /max pixel<0.9(When each color reaches its highest brightness) |
Effective control distance | Cat-5<100M,Multi-mode fiber:<500M;Single-mode fiber<20Km |
Color Temperature/contrast | Brightness and contrast of red, green and blue can be adjusted by software,100 scales are available, color temperature is adjustable |
Input signal | RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION |
Control system | Sending card+Receiving card+Hub card+DVI Card+PCTV Non-liner card+Muti-funcational card(Optional)+Video processor(Optional)+ Fiber Transmitter(Optional) |
2,Advantages 1) With 14 years experience in LED Encapsulation, form stable and high quality products. 2) Pass ISO9001-2000, and we have formed Perfect Management system guarantee quality strict control, which makes sure the quality well. 3) All the products are CE, RoHs 4) Powerful and experienced engineers and technician team would develop new products each year to cater to the requirement of the markets. 5) Advanced production equipment improve the production efficiency and quality. 6) Better after-service, we offer two years warranty for free, and lifetime maintenance, and offer free software upgrade service. 7) Free train after order, and offer you the train course in detail. 8) We have our engineering department which is responsible for the projects installation instructions, if you required, they can go to you to instruct you install the led screen. 9) Production capability: More than 1000sqm 10) High competitive value price ratio 3,Products series (1)Outdoor fix installation led screen:P10,P12,P14,P16,P20,P25 etc. (2)Outdoor rental led screen P10,P12,P14,P16,P20,P25 etc. (3)Indoor fix installation led screen:P6,P7.62,P8,P10 etc (4)Indoor rental led screen P6,P7.62,P8,P10 etc (5)Outdoor and indoor Perimeter LED Screen:P6,P7.62,P16,P20 etc (6)LED Curtain:P31.25,P37.5,P40 etc (7)LED Curve or Round,Column LED Screen: P6,P7.62,P8,P10, P12,P14,P16,P20,P25 (8)Dance floor led screen (9)Stage led screen (10)Single color or dual color for text and graphic

FAQ 1 Q: What is the Maximum. Inter space (gap) between cabinets? A: Inter space (gap) between cabinets within 1.5 mm for outdoor and 0.5mm for indoor. 2 Q: How to make the installation structure ? A: We offer the installation structure design drawings for customers, and the design can well fit your installation conditions. 3 Q: Do we need to follow some sequence in installation and keep every cabinet in its right position? A: All the cabinets are modular and every cabinet can be in any position, so there is no need to follow any sequence in installation since the sequence can be setup by software after installation. 4 Q: What is the cooling system of the display? Does the display need air conditioner? A: Every cabinet has fans for ventilation. We suggest customer to equip several industrial fans inside installation structure for ventilation instead of air conditioner. 5 Q: How to wire the cords and cables? A: Every cabinet one pair of power cords (output/input), and one pair of data cable (output/input), we make wiring instruction drawing for every order, customers only need to follow the instruction drawing. our service
1.Your inquiry related to our products or prices will be replied in 24hrs. |
2.Well-trained and experienced staffs to answer all your enquires in fluent English . |
3.OEM&ODM, any your customized screen we can help you to design and put into product. |
4.Distributoer ship are offered for your unique design and some our current models . |
5.Protection of your sales area, ideas of design and all your private information . |
