Outdoor DIP P10, P12, P16, P20, P25 full color led display led module

Outdoor full color led display led module DIP P10, P12, P16, P20, P25   P10 led module         P12 led module       P20 led module       P25 led module       Parameter table

Items		Outdoor LED Screen
Model		OFP10	OFP12	OFP12.5	OFP16	OFP20	OFP25
Module	Pixel Pitch	10mm	12mm	12.5mm	16mm	20mm	25mm
	Pixel density	10,000 dots/sqm	6,944 dots/sqm	6,400 dots/sqm	3,906 dots/sqm	2,500 dots/sqm	1,600 dots/sqm
	LED Encapsulation	DIP436	DIP436	DIP436	DIP546	DIP546	DIP546
	Led type	DIP	DIP	DIP	DIP	DIP	DIP
	Module Resolution	16*16dots	16*16dots	16*8dots	16*8dots	16*8dots	8*8dots
	Module size	160*160mm	192*192mm	200*100mm	256*128mm	320*160mm	200*200mm
	Pixel configuration	1R1G1B	2R1G1B	2R1G1B	2R1G1B	2R1G1B	2R1G1B
Main Technical Parameter	Best view distance	>8m	>10m	>11m	>14m	>18m	>22m
	White balance brightness	>6,000nit	>7,000nit	>7,000nit	>7,000nit	>6,500nit	>5,000nit
	Max power consumption	850w/sqm	850w/sqm	750w/sqm	1,000w/sqm	850w/sqm	600w/sqm
	View angle	120°/90°	120°/90°	120°/90°	120°/90°	120°/90°	120°/90°
	Refresh rates	>=1,200HZ	>=2000HZ	>=1200HZ	>=3000HZ	>=3000HZ	>=3000HZ
	Life span	>100,000 hours	>100,000 hours	>100,000 hours	>100,000 hours	>100,000 hours	>100,000 hours

                                                                                            Outdoor led display feature     Mainly for outdoor advertising, information publishing, journalism and communication in some places, such as cultural square, traffic arteries, stations, terminals, information centers, entertainment venues, shopping, centers, commercial city and etc.   1. High brightness DIP LED is used for outdoor led display, keeps the display content visible even if facing the strong sunshine directly.   2. With Anti-UV ray mask, the color of the mask would never change even if under exposure of UV ray.   3. Weatherproof design, completely outdoor use.   4. Easy for assembling and connection with the connector added.   5. High color uniformity and clear image can bring you a vivid audio visual effect.   6. Both front and rear access are available.                     7. The LED Chips that we use have the advantages of large viewing angle, low power consumption and good color uniformity.   8. Use the same level of red, green and blue led chips, which makes the image display of whole led display more excellent and uniform.   9. The maintenance of pixel and single led has been realized.   10. Good quality raw material, accurate technique and careful inspection insures the high quality of led display.   11. The shape and size can be made according to your requirement.     Outdoor led display screen           About us       BESDLED has 17 years experience of LED lamps encapsulation, 7 years of LED display screen, with complete special LED test lab, LED display R&D system, production system, QA, QC system. BESDLED passed ISO9001:2000 in 2004, our products also passed CE, ROHS approval. Our products have already exported to Europe, Asia, Africa and America and etc.   At BESDLED, we are committed to providing the highest level of customer service, competitive pricing, speedy delivery and a comprehensive, cutting-edge product offering.
