IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
  • IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
  • IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
  • IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
  • IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
  • IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
  • IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental
IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental

IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental

Delivery Time:
5 Days
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Place of Origin: Guangdong, China (Mainland)
Product Description
Product Description
IP65 BESD 12mm Pixel Pitch Outdoor Rental Use Full Color P12 led curtain for rental      The curtain series screens are designed with easy assembly and good transparency, outputting a high brightness of up to 5,000 nits with excellent colour uniformity for great visual effects whether indoor or outdoor. Now the curtain models add a whole new level of flexibility with the ability to convert a panel from curtain to solid display. Curtain panels are equipped with a specially designed angling system (with five angle options) enabling build of curved shaped screens in both horizontal and vertical formats, and in either convex or concave configuration. You can have the curtain sceens standing with external frame or being hanged from rigging truss. With advanced IP65 waterproof protection, curtain series panels are the smart choice for all rental companies requiring high flexibility and configurability.   FEATURES Waterproof - Advanced technology for SMD outdoor screen with full IP65 (front) protection Curve - Five angle options, build curved shaped screens Convex or concave assembly - Horizontal or Vertical assembly Brightness - Up to 5000cd/nits/m² high brightness with excellent color uniformity, ideal for outdoor stages Hot Swap - Innovative king pin and FastLock enables the flexibility of exchanging a panel from a complete screen Dot by Dot - Latest dot correction technology allows curtain series panels to achieve full color uniformity and brightness Fast - No tool assembly with fastlocks and compression locks for seamless assembly and performance Efficient - Low power consumption Circle - Assemble into complete circles     APPLICATIONS: Outdoor meetings and exhibitions Outdoor stage performance Outdoor talent shows Outdoor music concerts Other outdoor events

 Visual Parameter

 Pixel Pitch:

 12 mm

 Pixel Density:

 6944 pixels/m2

 Pixel Configuration:

 SMD3535(Black LED is available too)

 Module Dimension:

 288*288 mm

 Panels Dimension:

 576*576 mm

 Panels weight:

 11 kg/panel

 Panel Material:

 Aluminum profile

 Performance Parameter

 Brightness:

 >5000nits

 Best Viewing Distance:

 > 12m

Average Power Consumption:

 350 w/m2

 Max Power Consumption:

 850 w/m2

 Scan Mode:

 1/2 scan

 Viewing Angle:

 Horizontal: 120 degree, Vertical: 120 degree

 Gray Scale Level:

 14 bit

 Refresh Rate:

 >2200Hz

 LED Lifetime:

 >50,000 hours

 Environment Parameter

 Input Voltage:

 110/220/240v AC, 50/60Hz

 Operating Temperature:

 -20°C~60°C

 Operation Humidity:

 10%~90%RH

 Ingress Protection:

 Front IP65, rear IP54

 Control Parameter

 Control System:

 NOVA / LINSN

 Compatible video interface:

 YC, VGA, DVI, YUV, SDI, RGB, CVBS, HD-SDI

  All product specifications are for reference only and subject to change without prior notice; Please contact sales for details;     Packaging & Shipping   Similar Models        P31.25 led curtain    P16 led curtain   Company Information   >  Shenzhen BESDLED Co., Ltd  >  Set up at the ear of 1996 >  National level high tech enterprise, intergrating R&D, production, sales and engineering service. >  Factory area: 2,000 square meter, 4 storey building. >  High quality assembly lines, over 3000 sqm per monthly output >  Quality control: ISO9001:2008          P12 Outdoor Full Color LED Display Screen professional manufacturer :
