P10, P12.5, P16 indoor led curtain/ led mess display for stage

P10, P12.5, P16 indoor led curtain/ led mess display for stage

Get Latest Price

Delivery Time:: 3 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Guangdong, China (Mainland)

Product Description

P10, P12.5, P16 indoor led curtain/ led mess display for stage Specification: 1. 2 years warranty. 2. Lifespan:100000hours
3. Brightness:2000cd/sq.m 4. Refresh rates: >1200Hz 5. Displays are customized Product Description 1. SMD3-in-1 technology is used for indoor LED Display 2. Wide view angle: 140 in horizontal and 140 in vertical. 3. Special design and advanced SMT technology improves the heat dissipation. 4, With high refresh rate controller, guarantee that no scan line when taking photos. 5. Easy for assembling and connection with the connector added. 6, High color uniformity and clear image can bring you a vivid audio visual effect.

Module:BESD-IFP10		LED Type	smd3528
Pixel Pitch	10mm	Refresh frequency	2000Hz
Module Size	320x160mm	View Angle	140 0/1400
Module resolution	32x16pixel	Working Environment	Temp:-20°C~60°C, Humidity:10%~90%
Dot density	10,000pixel/sq. m	Working Voltage	AC:100V~120V AC:220~240V
Pixel configuration	1R1G1B	Lifetime	100,000Hours
The best view distance	>10m	Gray Scale	14bit/color
Cabinet dimension	960mmx640mm(Optional)	Color Display	1.07Billion
Cabinet resolution	32X40	Brightness	≥2000nit
Cabinet weight	50KG/sq. m	MITBF	0.00001
Drive mode	Constant current, 1/4 scan	IP	IP43
Max Power Consumption	400W/sq. m	Warranty	2 years
LED Parameter	R:d(625-630nm) R:IV(400-450mcd)	G:d(522.5-525nm) G:IV(1800-2200mcd)	B:d(467.5-470nm) B:IV(350-400mcd)
Image adjustment	Brightness, contrast, tone, color range etc
Brightness uniformity	Ratio of min pixel brightness /max pixel<0.9(When each color reaches its highest brightness)
Effective control distance	Cat 5<100M / Multi-mode fiber:<500M / Single-mode fiber<20Km
Color Temperature/contrast	Brightness and contrast of red, green and blue can be adjusted by software,100 scales are available, color temperature is adjustable
Input signal	RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION
Control system	Sending card+Receiving card+Hub card+DVI Card+PCTV Non-liner card+Muti-funcational card(Optional)+Video processor(Optional)+ Fiber Transmitter(Optional)

Application: 1. Wedding, Birthday party, Club, Band. 2. Concert, Event, Cultural square, Commercial centers, Packaging & Shipping 1. plywood box for fixed installation cabinet 2. flight case box for rental use cabinet, move easily 3. Box size is designed based on cabinet size

controll system 1. OEM&ODM,any your customized lighting we can help you to design and put into product 2. Top Quality + Reasonable Price + Responsible After Service = Successful & Win

Our Services 1. Free warranty for two years, each additional pay 4% a year. 2. For life to provide free installation and application of related technical guidance. 3. Obtained certifications: ISO9001:2008,CE,FCC,CCC,UL,RoHs,SGS (Special requirements for the certificate we provide to apply for assistance). 4. Accept different payment terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram,cash. 5. Software upgrade for free. Company Information

BESD Developing History:
From 1996 to 2014, SHENZHEN BESD LED CO.,LTD. Previous name Xinhongxiang Optoelectronics (shenzhen) Co.,Ltd, mainly involved in LED encapsulation and LED Display.,led lamps , led lights . Since 2010, owe to enlarge the company scale and build up self-owned brand, Rename to Shenzhen BESDLED Co.,LTD, business involved in indoor and outdoor LED Encapsulation, LED Display and LED Lighting Products.Comparing with many of LED Manufactures, BESDLED owns the following advantages to be your best choice for long term cooperation partner.
1, Fully automatic production lines
BESDLED owns the entire LED manufacturing line, encapsulate original Semiconductor to LED chip, then assemble to led displayand led lighting products.
2, Advanced production equipment
SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP led, Spectrum and Color Separation Machine, LED oven,Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and humidity programmable tester, luminance meter etc. are equipped for our LED Product production.
3, Many Certification approved to clear up the trade barriers
CE, FCC, UL, RoHS, CCC,ISO9001:2000 etc are obtained.
4,Strong R&D Team
BESDLED absorbs many talents, with more than 500 staffs, and including more than 100 engineers and technician, which paves the way for R&D for new products and excellent sales service

BESD Developing History:

From 1996 to 2014, SHENZHEN BESD LED CO.,LTD.

Previous name Xinhongxiang Optoelectronics (shenzhen) Co.,Ltd, mainly involved in

LED encapsulation and LED Display.,led lamps , led lights .

Since 2010, owe to enlarge the company scale and build up self-owned brand, Rename

to Shenzhen BESDLED Co.,LTD, business involved in indoor and outdoor LED Encapsulation, LED Display and

LED Lighting Products.Comparing with many of LED Manufactures, BESDLED owns the following

advantages to be your best choice for long term cooperation partner.

1, Fully automatic production lines

BESDLED owns the entire LED manufacturing line, encapsulate original

Semiconductor to LED chip, then assemble to led displayand led lighting products.

2, Advanced production equipment

SMD/DIP die bolder, SMD/DIP wire Bolder, Auto Machine of Pouring Glue for SMD/DIP led,

Spectrum and Color Separation Machine,

LED oven,Wave solder, Reflow soldering, Spectrum electronic and color tester, temperature and

humidity programmable tester, luminance meter etc. are equipped for our LED Product production.

3, Many Certification approved to clear up the trade barriers

CE, FCC, UL, RoHS, CCC,ISO9001:2000 etc are obtained.

4,Strong R&D Team

BESDLED absorbs many talents, with more than 500 staffs, and including

more than 100 engineers and technician,

which paves the way for R&D for new products and excellent sales service

FAQ Q1: Do you have other indoor LED display series? A: Yes. We also provide P2.5,P3,P4,P5,P6,P7.62,P8,P10. Q2:Do you have other outdoor series? A:Yes.We provide outdoor LED display series: P6,P8,P10,P16,P12,P12.5,P20,P25. Q3: I have special requires? A: We will do our best to make the best solution for you. Q4: I want to know more? A: Contact us right now is the fastest way.
