FPV 7 inch Monitor Integrated With 5.8G Receiver, DVR Recorder 3-in-1

Specifications FPV 7 inch Monitor

1.Integrated With 5.8G Receiver

2.DVR Recorder 3-in-1

FPV 7 inch Monitor Features 1. No Blue Screen                                                                         1.Wireless FPV
2.  FPV Portable DVR                                                                     2.Baby Monitor
3.  TF Card Support up to 32G  (not included)                               3.Wireless Visual Reversing Camera Transmission
4.  High Video Quality                                                                    4.DVD/DVB AV Wreless Transfer
5.  Speaker                                                                                    5.Engineering Construction Monitor 7.  Receiving Sensitivity:-90dBm                                                      6.Wireless Video Leisure Goods
8.  Frequency Control:built-in Frequency and Phase Lock Loop      7.Wireless Camera Security System
9.  Support Wired & Wireless Camera, Photo Function,                    8.Wireless Video Medical Apparatus
10. Motion Detection, Cycle Recording                                              9.Wireless Doorbell
This DVR is the ideal choice for security & protection, evidence & investigation, like police, household, sports, automotive industry, shops, etc..
Power off  Without Video Lost
Photo Function: It Can Take, Review & Store Pictures
Seamless Continuous Record:No Intermittent Recording, it will not Miss any  Detail and Wonderfulness
Resolution
D1(720×576),VGA(640×480)QVGA(320×240),Higher Resolution,Bigger File.
Cycle Recording
Overwrite: It supports loop recording, which can automatically overwrite
when storage is full;TF card life is longer than normal DVR with unique algorithm
Motion Detection
Motion Detection Available : Record Only when there is movement
Motion detection sensitivity
It is adjustable according to the situation
Day Label
Optional to show the day label when video recording Voice Record
 Voice record is optional when video recording Product Details Display
Model:PVR-758
Resolution:1024 x 600 Pixels
Aspect Ratio:16:9
Brightness:250cd/m2
Contrast:700:1
Response Time :10ms
Backlight:LED
Support Video Format:PAL-4.43; NTSC-3.58
Viewing Angle"75°/75°(L/R)75°/75°(U/D) Input
Input Singnal :Video\Audio \RF \HDMI(Optional)
HDMI Support Mode:480i\480p\576i\576p\720p\1080i\1080p(50/60Hz)
Output
Output Singnal:VIDEO
Earphone Output:3.5mm Audio output
Power
Input Voltage:DC:6-24V
Power Consumption:≤8W
Enrivonment
Install Way:Includes a standard 1/4-20 tripod mounting hole on
the bottom for simple use in your ground station!
Working Temperature:-20-50°C
Storage Temperature:-30-65°C
Dimension
TF Card Max up to:32G  (not included)
Size:189(L)x134(W)x32(H)mm
Weight:450g Antenna connector: RP-SMA, jack (monitor side) See connector type diagram  FOR SIGNAL INPUT CONNECTORS, OUR VERSION COME WITH 3 BNC TO RCA CONVERSION CONNECTORS, SO YOU CAN CONNECT THE MONITOR WITH BOTH RCA OR BNC INPUT.  THE MANUFACTURER USES SAME OUTER PACKING FOR MANY DIFFERENT VERSIONS OF PRODUCTS, SO THERE MAY HAVE MANY DISCREPANCIES  ON THE OUTER PACKING, PLEASE DISREGARD THOSE DISCREPANCIES IF ANY. Item Packing monitor X 1
2db antenna X 1
Sony F970 battery plate (pre-installed)   X 1
 BNC to RCA adaptors  X 3
sunlight shield X 1
HDMI cable X 1
instruction manual X 1
