Foxeer HS1177 SONY 600TVL CCD CAMERA 2.8MM LENS

Foxeer HS1177 SONY 600TVL CCD CAMERA 2.8MM LENS     This is a mini version of the classic CC1333 600TVL Sony Super Had II CCD board FPV camera. It uses a 1/3" Sony Super HAD II CCD, Nextchip 2040 DSP, D-WDR, 2D-DNR, minimum illumination reach 0.01 Lux (black/white) with a powerful OSD.   A customized 3pin servo cable is also included.       NOTE: This is the plastic cased version of this camera. See the related items for the heavier metal cased version.       Features:   - 600TVL high picture quality - 1/3" SONY SUPER HAD II CCD - Nextchip 2040 DSP - Powerful OSD menu - D-WDR (Wide Dynamic Range) - 2D-DNR (Digital Noise Reduction) - Low Power Consumption(70mA) - Mirror function - Privacy areas: 8 areas - Low illumination: 0.01Lux - 2.8mm Lens - Low Power Consumption - Suitable for FPV        Specifications:   - Model: HS1171 - CCD: 1/3” Sony SUPER HAD II CCD - Pixel: PAL: 976(H) x 494(V);NTSC: 768(H)×494(V) - TV System: PAL/NTSC(according to country) - Resolution: 650TVL(b/w), 600tvl(color) - Synchronization : internal synchronize - Shutter Speed: (CCD IRIS) PAL: 1/50~1/100000 sec; NTSC: 1/60~1/100000 sec - Noise: > 60 (AGC OFF) - Video Out: 75ohm, synchronize - Min. Illumination: 0.01Lux - Auto Gain: Off/Low/Mid/High - Back Light Compensation (BLC): Off /Back light compensation/ Strong light suppression - Private shading (PRIVACY): 1~8 private shading area - Motion Detection (MD): On/ Off (Multi level sensitivity settable) - Auto White Balance: Manual / Auto / Auto track - Mirror: Horizontal Mirror optional - Negative: Positive / Negative optional - Color to B&W: Auto - DNR: 2DNR - WDR: D-WDR - Day / Night Shift: Auto/ Color/ B&W - Menu (OSD): English menu - White Dot Repair: Support - Image Adjustment: Support - Camera Title: Support - Power Requirement: DC5V~22V - Working Temperature: -10 C ~ +50 C - Working Humidity: 20~80% - Storage Temperature: -40 C ~ +60 C - Storage Humidity: 20~95% - Dimensions(mm): 25X25(W*L) - Power Consumption: 70mA
