XERUN V10 Competition Motor 5.5T 6450KV

Specifications 1.XERUN V10 Competition Motor 5.5T 6450KV

Features -Compliant with ROAR and IFMAR rules
-Mechanical timing adjustable
-200°C high temperature high purity copper windings maximizes conductivity and reliability
-Super low resistance multi-layers outlet PCB (Printed Circuit Board)
-Removable / replaceable rotor
-High RPM precision bearings (Brand: NSK)
-Powerful high temperature sintered NdFeb (Neodymium) magnets
-High efficiency of energy conversion Product Details

odel	PN	KV	Resistance Ohm	Current w/o Load  Amp	Maximum Output Power* W	Current @Max. Output Power* Amp	Dimension mm	Weight g	Rotor
3.5T	30401020032	9700	0.0026	9.2	600	130	Can Ø=36 L=52.5 External Shaft Ø=3.17 L=14.6	173	V10-Ø5-12.5F
4.5T	30401020033	7650	0.0040	6.9	490	108		169
5.5T	30401020034	6450	0.0061	5.8	430	100		172	V10-Ø5-12.5
6.5T	30401020035	5340	0.0080	4.1	390	94		170
8.5T	30401020036	4165	0.0138	3.2	340	80		168
10.5T	30401020037	3450	0.0208	1.9	250	63		174	V10-Ø7-12.5
13.5T	30401020038	2760	0.0330	1.6	190	49		178
17.5T	30401020039	2210	0.0620	1.1	130	34		172
21.5T	30401020040	1760	0.0890	0.9	100	28		174

     Item Packing   -XERUN V10 Competition Motor 5.5T 6450KV x 1
