FOXTECH FPV 2.4G 500mW A/V Transmitting/receiving System

Get Latest Price

Delivery Time:: 1 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	China (Mainland)

Product Description

Specifications 1.FOXTECH FPV 2.4G 500mW A/V Transmitting/receiving System

2.Transmitting unit weight:34.5g

3.Power input: 12V

Specifications:
FOXTECH FPV 2.4G 500mW A/V Transmitting/receiving System
Transmitting unit weight: 34.5g
Power input: 12V ± 5%
Receiving current: 100mA
Transmitting current: 200mA
Channel number: 8-ch
Transmitting distance (air to ground): 1 to 2Km (for reference only, the distance may vary a lot depending on the environments)
Antenna gain: 3db
Video signal resistance: 75Ω
Antenna connection: SMA
Working frequency: CH1/CH5: 2410/2370MHz
CH2/CH6: 2430/2390MHz
CH3/CH7: 2450/2490MHz
CH4/CH8: 2470/2510MHz Includes/Requires:
Includes:
1 x transmitting unit
1 x receiving unit
1 x basic wires * No instruction manual supplied with this product.
