30W metal laser tube marking machine

Specifications 1) high precision portable fiber laser marking machine

2) stable performance

3) simple operation

4) convenient maintenence

30W metal tube laser marking machine Model pic: Product Description: RF  CO2 laser marking machine,used the American RF laser device with high power and frequency,long useful life,high marking speed,powerful and flexible laser scanner. The strong anti-interference ensure the system stability in the long-term working station.   Features: Laser:adopted the American laser device,stable output beam,less fault,the lifespan to 25000 hours,low maintenance cost.Reasonable overall design with the world advanced design,control system,galvanometer combine each other perfectly,increasing the component lifespan. Cooling system:Used optimized air cooling or water cooling system to enhance laser tube useful life,operate easily and conveniently.   Technical Parameters:

Specification	Parameters
Laser Power	30W
Laser Source	Coherent or Synrad CO2 Laser
Wavelength	10.64μm
Laser Power	30W
Power Stability	≤0.5%
Focus Facula Diameter	20μm
Laser Accuracy	0.0025mm
Beam Size	0.1mm
Beam Divergence	<5
Expect Service Life	20,000hrs
Indication Beam	Red Light
Wavelength of Indication Beam	635nm
Cooling	Air Cooling
Work Area	200×200mm(option)
Laser Head	Servo Motor Gavol Scanner
Maximum Speed	≤315 in./s(8000mm/s)
Repeated Frequency	20kHz~100kHz
File Formats	PLT, PCX, DXP, BMP, JPG etc
Output Compatibility	AutoCAD, CorelDRAW, Photoshop etc
Marking Varieties	Words, Pictures, Bar-codes, Logos, Serial Numbers etc
Advantages	Best performance for marking on nonmetal materials
Facility Requirements
Electrical	220V/50Hz(Customized)


   Application field
1, suitable for beverage, food, pharmaceutical, wine and tobacco, chemical, electronics, leather, ceramic, rubber and other industries a variety of material surface beautiful, high-definition, permanent information identification
2, can print text, data, batch number, serial number, qr code, bar code, design and real time, print the number of rows and direction is not restricted
3, print character height is between 0.3 mm to 120 mm flexible choice, applicable to the static and dynamic production line at a high speed.
Widely suitable for various metals, alloy, metallic oxide materials and some non-metallic materials(silicon wafer, ceramics, plastic, rubber, epoxy resin, ABS, printing ink, plating, spraying, coating film and etc.external materials).   Samples: We also provide other machines:
