Basic Info

Place of Origin:	German

Product Description

Gea Kuba Ceiling Type refrigeration evaporator Air Cooler for Cold Storage, Cold Room, Supermarket

Specifications:

1,The high efficient coils are made from high equality copper tubes and special aluminum fins.

2,Heat Exchangers are supplied clean and tested under a pressure of 30 bars.

3,The casing----White power coated aluminum, corrosion strength, impact resistance, and does not produce poliuting debris.

4,The fan motors-----All with high quality axial fan motors with high satety standards fitted well to the unit casing with an anti-vibration system.

5,Defrost heating----Provided by stainless steel heater elements covered by the aluminum tubes. Located in the finned pack and in the drain pan.

6,Electrical parts and wiring-----are connected to an earth terminal, carried out in junction box with access holes equipped with water-proof cable grands.

7,All material are selected carefully for long-term reliability.

8,A-level agent of German GEA kuba evaporator for cold storage, supermarket etc.

More Models please check as below:

Model	Rated Capacity (kw)		External Surface (m2)	Air Flow (m3/h)	Air Throw (m)	Tube Volume (dm3)	Connection (Φmm)
Model	t=8 DT1=8K	t=25 DT1=7K	External Surface (m2)	Air Flow (m3/h)	Air Throw (m)	Tube Volume (dm3)	Inlet
DPA 031C	3,69	5,41	16,3	1720	2x11	3,4	10*
DPA 041C	4,26	6,25	24,3	1620	2x9	5,1	10*
DPA 032C	7,38	10,8	32,6	3440	2x12	6,8	10*
DPA 042C	8,52	12,5	48,6	3240	2x10	10,2	10*
DPA 033C	11,1	16,3	48,9	5160	2x13	10,2	10*
DPA 043C	12,8	18,8	72,9	4860	2x11	15,3	15*
DPB 031C	2,98	4,37	11,0	1850	2x11	3,4	10*
DPB 041C	3,72	5,46	16,4	1770	2x9	5,1	10*
DPB 032C	5,96	8,75	22,0	3700	2x12	6,8	10*
DPB 042C	7,44	10,9	32,8	3540	2x10	10,2	10*
DPB 033C	8,94	13,1	33,0	5550	2x13	10,2	10*
DPB 043C	11,2	16,4	49,2	5310	2x11	15,3	15*
DPB 034C	11,9	17,5	44,0	7400	2x14	13,6	15*
DPB 044C	14,9	21,8	65,6	7080	2x12	20,4	22*

Model	Rated Capacity (kw)		External Surface (m2)	Air Flow (m3/h)	Air Throw (m)	Tube Volume (dm3)	Connection (Φmm)		Sound dB (A)	Blade
Model	t=8℃ DT1=8K	t=25℃ DT1=7K	External Surface (m2)	Air Flow (m3/h)	Air Throw (m)	Tube Volume (dm3)	Inlet	Outlet	Sound dB (A)	Blade
SPA 011D	1,65	2,44	6,9	820	4	1,4	10	12	63	1 x 250
SPA 021D	1,80	2,65	9,1	760	4	1,9	10	12	63	1 x 250
SPA 031D	2,65	3,93	10,3	1380	6	2,1	10	18	70	1 x 300
SPA 041D	3,00	4,44	13,6	1300	5	2,8	12*	22	70	1 x 300
SPA 051D	6,05	8,98	20,5	3020	8	4,2	12*	28	77	1 x 400
SPA 061D	6,83	10,1	30,6	2720	7	6,3	12*	28	77	1 x 400
SPA 071D	11,3	16,8	36,3	5800	17	7,6	15*	35	83	1 x 500
SPA 081D	13,1	19,3	54,2	5270	16	11,1	15*	35	83	1 x 500
SPA 022D	3,62	5,34	18,2	1520	6	3,6	12*	22	66	2 x 250
SPA 032D	5,33	7,90	20,6	2760	8	4,1	12*	28	73	2 x 300
SPA 042D	6,02	8,92	27,3	2600	7	5,5	12*	28	73	2 x 300
SPA 052D	11,9	17,7	40,9	6040	12	8,2	15*	35	80	2 x 400
SPA 062D	13,4	19,7	60,9	5440	11	12,1	15*	35	80	2 x 400
SPA 072D	21,7	31,9	72,7	11600	22	14,3	15*	42	86	2 x 500
SPA 082D	25,7	37,9	108,3	10540	21	21,5	22*	42	86	2 x 500
SPA 023D	5,51	8,16	27,3	2280	8	5,3	12*	28	68	3 x 250
SPA 043D	8,96	13,3	40,9	3900	10	8,0	15*	35	75	3 x 300
SPA 053D	18,2	27,0	61,4	9060	15	12,0	22*	42	82	3 x 400
SPA 063D	20,6	30,4	91,5	8160	13	18,0	22*	42	82	3 x 400
SPA 073D	33,4	49,5	109,2	17400	26	21,3	22*	54	88	3 x 500
SPA 083D	38,3	56,3	162,7	15810	24	32,2	22*	54	88	3 x 500
SPA 024D	7,26	10,7	36,3	3040	9	7,1	12*	28	69	4 x 250
SPA 044D	11,7	17,2	54,5	5200	12	10,6	15*	35	76	4 x 300
SPA 064D	26,9	39,6	122,0	10880	16	23,7	22*	42	83	4 x 400
SPA 074D	43,5	64,1	145,5	23200	28	28,6	22*	54	89	4 x 500
SPA 084D	51,6	76,1	216,9	21080	26	41,0	28**	54	89	4 x 500
SPA 065D	34,1	50,4	152,4	13600	18	28,9	22*	54	84	5 x 400
