Brass Danfoss valves Model T12 , Refrigeration Parts Thermo
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | China/Europ |
|---|
Product Description
Product Description
Danfoss valves Model T12 - With Interchangeable Orifice Assembly
Specifications:
- Regriratant:R404A/R22/R134a
- Thermostatic expansion valve regulate the flow of refrigerant liquid into The evaporator.
- The flow is controlled by the valve is thermal bulb which is Attached to the suction line at the outlet of the evaporator.
- The thermal Bulb senses the evaporator heat and adjusts the valve to admit refrigerant Liquid in accordance with the refrigerating load.
| Danfoss Model T12 - With Interchangeable Orifice Assembly | |
| Part Number | Description |
| T12 Power Assemblies | |
| 067B3210 | VLV TX DANF R22 POWER ASSY EXT. |
| 067B3232 | TEN12, R134A, POWER ASSY, EXT. EQ. |
| 067B3347 | VLV TX DANF R404A POWER ASSY EXT. |
| T12 Orifice Assembly | |
| 067B2005 | ORIFICE DANF TE12 SERIES NO.1 |
| 067B2006 | ORIFICE DANF TE12 SERIES NO.2 |
| 067B2007 | ORIFICE DANF TE12 SERIES NO.3 |
| 067B2008 | ORIFICE DANF TE12 SERIES NO.4 |
| T12 Valve Body | |
| 068B4020 | VLV BODY TE12 STRAIGHT SOLDER |
| 068B4021 | VLV BODY TE12/20 STRAIGHT SOLDER |
| 068B4022 | VLV BODY TE12 ANGLE SOLDER 5/8 |
| 068B4023 | VLV BODY TE12/20 ANGLE SOLDER |
| 067B4026 | VLV BODY TE12 STRAIGHT FLANGE |
