10.1inch TFT LCD Screen in High Quality/Resolution 1024X600
  • 10.1inch TFT LCD Screen in High Quality/Resolution 1024X600
10.1inch TFT LCD Screen in High Quality/Resolution 1024X600

10.1inch TFT LCD Screen in High Quality/Resolution 1024X600

Get Latest Price
Min. Order:
1 Piece/Pieces
Min. Order:
1 Piece/Pieces
Quantity:

Your message must be between 20 to 2000 characters

Contact Now
Basic Info
Basic Info
Product Description
Product Description

Basic Info.

Model NO.
RG-T101BAH-02
Widescreen
Not Widescreen
Response Time
25ms
3D
Not 3D
Interface Type
Lvds
Brand
Rongen
Product Name
Rg-T101bah-02
Resolotion
1024X600
Luminance
350CD/M2
Size
10.1inch
Contrast Ratio
500: 1(Typ. )
Response Time(Ms)
15/20 (Typ. )(Tr/Td)(Ms)
Operation Temperature
-30 ~ 85 °
Transport Package
Stardard
Specification
CE, RoHS, SGS
Trademark
Rongen
Origin
China
HS Code
9013803010
Production Capacity
100, 0000/Month

Product Description

High Quality 10.1inch TFT LCD Screen

Item Contents
 LCD Type  TFT
 Display Color  16.7M
 View Direction  12 O'Clock
 Gray Scale Inversion Direction  6 O'Clock
 Operating Temperature  -20+70 °C
 Store Temperature  -30~+80 °C
 Module Size  Refer to outline drawing
 Active Area(W×H)   222.27X125.28 mm
 Number of Dots 1024×600 dots
 Controller HX8282A14+HX8696
 Power Supply Voltage  3.3V
 Outline  Dimensions  Refer to outline drawing
 Backlight 3x13-LEDs(white)
 Weight
 Interface  RGB888



Our LCD module size are from 1.77 inch to 10.4 inch which are widely used in digital camera, DV, security monitoring, carcorder, PMP, MID and Education Learning Aid, POS Machine etc.

Product Application
Small-size TFT LCD display mobile device,watch,toy,medical equipment, Office electronic equipment,camera, air-condition display, etc.
Mid-size TFT LCD display mobile device,medical equipment,car, automotive product,industrial control equipment,POS,PDA, Household Video doorbell, air-condition display,etc.
Big-size TFT LCD display educational product,automotive product,video door phone, Audiovisual equipment,DVD player,media play,tablet PC, Security Products,etc.
TN/STN//FSTN/OLED  elevator controller,watch,electronic product,air-condition display,all kinds of instrument,etc.
Plastic mould industrial control equipment,electronic product,toy, Security Product,IT digital product, sports equipment,etc.


10.1inch TFT LCD Screen in High Quality/Resolution 1024X60010.1inch TFT LCD Screen in High Quality/Resolution 1024X60010.1inch TFT LCD Screen in High Quality/Resolution 1024X60010.1inch TFT LCD Screen in High Quality/Resolution 1024X60010.1inch TFT LCD Screen in High Quality/Resolution 1024X60010.1inch TFT LCD Screen in High Quality/Resolution 1024X60010.1inch TFT LCD Screen in High Quality/Resolution 1024X60010.1inch TFT LCD Screen in High Quality/Resolution 1024X60010.1inch TFT LCD Screen in High Quality/Resolution 1024X60010.1inch TFT LCD Screen in High Quality/Resolution 1024X600
Why Choose Rongen Display?

  • FOG automatical device can ensure the capacity of 1000,000 per month.

  • Reliability test and full examination to ensure the high quality of the display.

  • Strictly ISO quality management system.

  • Mature and Professional after service.

  • Various cooperation experience with big brands.
    10.1inch TFT LCD Screen in High Quality/Resolution 1024X600
