IP65 Dynamic Metal Industrial Mini Keyboard With Optical Trackball
Special Features:
1. 25.0mm opticlal washable trackball with 800DPI resolution.
2. CE,RoHS,FCC certificate,IP65, ESD
3. 102keys Compact Format IP65 static Vandal Proof Stainless Steel industrial Keyboard
4. Function keys F1, F2..F10, F11, F12 are on the top panel for easy operation
5. 3 mouse buttons designed for right & left clicking and scrolling up and down with ball rolling,
6. With rear panel mounting solution
7. Ease of customizing with multiple languages, to accommodate foreign or custom variants.
8. PS/2, USB connection plug-and-play with PC via PC existing OS driver, no needing of install separate driver
9. Industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm
Applications:
This Keyboard is mainly targeted for use for:
A: unsupervised or semi -supervised positions of varied access applications,
B: internet terminals and information kiosks at universities,
C: shopping malls, hotels, airports, railway stations and other public areas,
D: ticket vending machines, gas stations, cash machines (ATMs), Internet public phones etc.
Specifications:
|
MECHANICAL DATA |
|
|
Key |
102 keys, super quality SUS304 brushed stainless steel |
|
Key top style |
Non-Protuberant rectangular keys, with laser engraved and etched legends and raised braille on keys are available |
|
Key Size |
10.0mm x 10.0mm for normal keys, |
|
Key travel |
0.45mm |
|
Tracker ball |
25.1mm (1.0’) diameter |
|
Switch life |
more than 5 million of operations |
|
Actuation Force |
1.50N+/-0.1N for key 10.0mm x 10.0mm (pressure point) |
|
Front Plate |
1.5mm thickness super quality brushed stainless steel |
|
Back Plate |
3.0mm thickness brushed & oxidized aluminum |
|
Actuator/keys materials |
stainless steel |
|
G.W. |
1.6 0KGs |
|
Dimensions |
312.0mm x 105.0mm (top panel) , 332.0mm x 117.80mm (rear panel) |
|
ELECTRICAL DATA |
|
|
Supply Voltage |
+5V DC +/-5% |
|
Current Rating |
appr. 30mA |
|
|
It is compliance with the council IEC 61000-4-2:2008; |
|
EMI: |
EN 55022: 2010 |
|
EMS: |
EN 55024:2010 |
|
Lifespan |
> 5 years |
|
Switch Contact Material: |
metal dome PCB with Gold-on-Gold key switch technology |
|
If needed, numeric keypad is available to be with encryption electronics controller |
|
|
Interface: |
Interface: PS2, USB available, RS232 for EPP |
|
OS: |
All windows, Linux, Unix, Mac OSX |
|
ENVIRONMENTAL ADAPTABILITY |
|
|
Operating temperature |
-20oC to +60oC |
|
Storage temperature |
-30oC to +70oC |
|
Operating RH |
30-90% |
|
Atmospheric pressure |
60-106Kpa |
|
Saline mist |
96 hours, IEC 60512-6 |
|
Damp heat test at + 40oC |
21 days, IEC 60512-6 |
|
Dry heat test at + 85oC |
10 days, IEC 60512-6 |
|
RELIABILITY |
|
|
Certification |
RoHS Compliant, CE and FCC,IP65,ESD |
|
Protection Level |
IP65(front panel) |
|
Vandal resistant |
IK10 |
|
Key Lifespan |
>5 million actuations |
|
MTBF |
>50000H |
|
MTTR |
<30min |
