Rugged weather proof industrial PC keyboard with numeric keypad
Special Features:
1. Imposing stainless steel design, specially designed keyboards meet the highest demands with regard to design,functionality, longevity and high protection level.
- IP65 dynamic vandal proof stainless steel industrial kiosk keyboard with numeric keypads and functional keys
- movable stand alone DESK TOP VERSION, or mountable desktop with mounting holes on the bottoms for fixing
- Metal keys are protected against twisting and levering which can not be dislodged from front, or defaced removing key covers.
- An excellent tactile feel with short stroke switches and allow users to achieve stable and accurate data input, with firm tactile perception for comfortable operation
- industrial metal dome PCB with gold-on-gold key switch technology with short stroke 0.45mm with excellent tactile feeling for stable and accurate data input
- PS/2, USB connection plug-and-play with PC via PC existing OS driver, no needing of install separate driver.
- Ease of customizing with multiple languages, to accommodate foreign or custom variants.
Applications:
This Keyboard is mainly targeted for use for:
A: unsupervised or semi -supervised positions of varied access applications,
B: internet terminals and information kiosks at universities,
C: shopping malls, hotels, airports, railway stations and other public areas,
D: ticket vending machines, gas stations, cash machines (ATMs), Internet public phones etc.
Specifications:
MECHANICAL DATA |
|
Key |
95 keys, super quality brushed stainless steel |
Key top style |
Non-Protuberant rectangular keys, with laser engraved and etched legends and raised braille on keys are available |
Key Size |
14.0mm x 14.0mm for normal keys, |
Key travel |
0.45mm |
Switch life |
more than 5 million of operations |
Actuation Force |
2.0 N +/-0.1N for key 14.0mm x 14.0mm (pressure point) |
Stainless Steel Housing |
Full 1.2mm thickness super quality brushed stainless steel |
G.W. |
2.30KGs |
Dimensions |
343.0mm x 148.0mm x 20.0mm (L x W x H) |
ELECTRICAL DATA |
|
Supply Voltage |
+5V DC +/-5% |
Current Rating |
appr. 20mA |
EMC Standard: |
It is compliance with the council IEC 61000-4-2:2008; |
EMI: |
EN 55022: 2010 |
EMS: |
EN 55024:2010 |
Lifespan |
> 5 years |
Switch Contact Material: |
Gold-on-Gold key switch technology PCB. |
Interface: |
PS2, USB available. |
OS: |
All windows, Linux, Unix, Mac OSX |
ENVIRONMENTAL ADAPTABILITY |
|
Operating temperature |
-20oC to +60oC |
Storage temperature |
-30oC to +70oC |
Operating RH |
30-90% |
Atmospheric pressure |
60-106Kpa |
Saline mist |
96 hours, IEC 60512-6 |
Damp heat test at + 40oC |
21 days, IEC 60512-6 |
Dry heat test at + 85oC |
10 days, IEC 60512-6 |
RELIABILITY |
|
Certification |
RoHS Compliant, CE and FCC,IP65,ESD |
Protection Level |
IP65(front panel) |
Vandal resistant |
IK10 |
Key Lifespan |
>5 million actuations |
MTBF |
>50000H |
MTTR |
<30min |
