Universal AC To DC Television Power Adapter , 2 Pole US Type , RoHS And Reach
Feature:
Universal AC input
2 pole US
Class II power (without earth pin)
No load consumption < 0.3W
Full output 3.3Vdc~22.0Vdc safety approval
Protections: Overload, Short Circuit
Approved by UL/CE/CB/C-TICK
2 year warranty
Description:
|
Electronics Specification: |
|
|
Input Voltage Range: |
90~264Vac |
|
AC current: |
0.2A |
|
Frequency: |
50/60Hz |
|
Inrush Current: |
30A/230Vac |
|
Leakage Current: |
0.25mA/240Vac |
|
Output Voltage: |
3.3~22.0Vdc |
|
Voltage tolerance: |
±5% |
|
Line regulation: |
±1% |
|
Load regulation: |
±5% |
|
Efficiency: |
Meet energy star level V(CEC) |
|
Over current protection: |
Hiccup mode, Auto recovery |
|
Over voltage protection: |
Power shutdown, Auto recover |
|
Environment |
|
|
Working Temp.: |
0~40℃ |
|
Working Humidity: |
20%~90% RH non-condensing |
|
Storage Temp. & Humidity: |
-20℃~85℃, 10%~95% RH |
|
Reliability |
|
|
Hi-Pot Testing Voltage : |
I/P to O/P : 3.0 (60Sec.) KVac |
|
Safety Standard : |
EN60950 |
|
EMI Standard : |
EN55022B |
|
Safety Approval: |
|
|
Certificate |
UL, CE, FCC, C-TICK,CB |
|
Mechanical Characteristics |
|
|
Size: |
65mm*40mm*32mm (L*W*H) |
|
AC connector |
US type |
|
DC Cable: |
1.8M |
|
DC connector: |
5.5*2.1*12mm, other type connector avaible |
Output Data
|
Model No. |
Voltage |
Current range |
Ripple & Noise |
Eff. |
|
P033W2000U |
3.3V |
0.1~2.0A |
50mV |
>65% |
|
P050W1000U |
5.0V |
0.1~1.0A |
50mV |
>72% |
|
P050W1500U |
5.0V |
0.1~1.5A |
50mV |
>72% |
|
P060W1250U |
6.0V |
0.1~1.25A |
60mV |
>72% |
|
P075W1000U |
7.5V |
0.1~1.0A |
75mV |
>72% |
|
P090W0830U |
9.0V |
0.1~0.83A |
90mV |
>72% |
|
P120W0625U |
12.0V |
0.1~0.625A |
120mV |
>75% |
|
P150W0500U |
15.0V |
0.1~0.50A |
150mV |
>75% |
|
P190W0400U |
19.0V |
0.1~0.40A |
190mV |
>75% |
|
P200W0375U |
20.0V |
0.1~0.375A |
200mV |
>75% |
|
P220W0340U |
22.0V |
0.1~0.34A |
220mV |
>75% |
Certificate:
Applications:
widely used in household appliances, IT digital products, medical equipments, communication equipments, instrumentations, bank data equipment, computer peripheral products, security monitoring system, industrial and light field equipment and other products.
