P8 Digital Electronic LED Outdoor Signs Waterproof RGB Color Synchronous Control
Quick Details:
1.8mm pixel rgb, hd, big density, very bright
2. 2 years' warranty for entire screen.
3. hotline service, fast response.
4. on-site professional service.
5. adequate spare parts supply.
6. regular maintenance service.
7. technical support on upgrades and replacement.
8. Communication Type: 3G, Wifi, Cats≤100m, Multimode optical fiber≤500m, Single Mode Optical Fiber≤1500m
Function and Technology Character:
1. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive.
2. Information source can be camera, video, VCD, DVD, LD, TV and so on.
3. Clear picture without flicker and distortion.
4. Brightness, contrast, saturation can be adjust by itself and manual.
5. Show everything with your PC does synchronously.
6. Super correcting technology for distortion.
7. Multiform language editions, such as English, French, Germany, Greek, Russian and so on
8. Connected and controlled by PC via Lan and remote control. One interface for sound signal and two for video signal at least.
Application and function:
Suit for advertisement, stage, stadium, exhibition, TV-Show, mansion video wall, shopping mall, banks, schools, bus station, airport, gym, market, factories, monitoring centers, hospitals, bars etc.
1. Video display for advertisement
2. Live broadcast for news, sport, concert…
3. Stage background
4. Information display for time, schedule, text
5. Dynamic display for logo, text, video
Specifications:
| Model NO.AD-O-F-P8-01 LED Outdoor Signs DIP P8 | |
| Pixel pitch | 8mm |
| Module dimension | 256mm*128mm |
| Cabinet dimension | 768mm*768mm or other sizes based on the module size |
| Density | 15625 Dots/sqm |
| LED standard | DIP 236 |
| Brightness | 7500cd/ sqm |
| Protection level | IP 65 |
| Pixel configuration | 1R1G1B |
| Control mode | Synchronous/Asynchronous |
| Module/Resolution | 32*16 |
| Cabinet/Resolution | 96*96 |
| Module/Cabinet | 3*6 |
| Driving method | constant driving 1/4 scan |
| Viewing angle | H:110° V:55° |
| The optimal viewing distance | 8-100m |
| Consumption | Max.800w/ sqm |
| Average.350w/sqm | |
| Refresh rate | 800Hz |
Excellent display:
1. High-contrast mask design: new anti-glare mask design, fine sand processing and black coating on the surface, no glare, and improve the contrast.
2. Automatic SMT: adopting high-end automatic SMT machine, advanced wave soldering and reflow soldering processing, to effectively avoid the wrong plug, plug leakage, leakage welding, virtual welding problems.
3. Module suite: improve the planeness of the whole screen, and reduce the seam between the neighboring modules.
4. Multi gray display: adopting 16bit gray processing technology to restore the natural image. And using S-PWM driving technology to add gray grade, meet the 16bits high gray display requirements with low brightness.
5. Point by point correction: the correction technology of brightness and chromaticity to ensure the uniformity of led screen’s brightness and color.
Variety and easiness:
1. Various installation: cabinet assembly or magnetic suction installation
2. Easy maintenance: optional front maintenance, back maintenance and single point maintenance according to the installation site.
3. High contrast mask design
