BK7 Precision Dove Prisms Optical Prism For Beam Rotator Orientation
Dove prisms
Specifications:
|
Dimensional Tolerance (mm) |
±0.1 Legs, ±0.15 Hypotenuse |
|
Surface Accuracy (λ) |
1/4 |
|
Surface Quality |
60 - 40 |
|
Angle Tolerance (arcminutes) |
2 |
|
Bevel |
Protective bevel as needed |
|
Substrate |
N-BK7 |
|
Coating |
Uncoated |
|
Type |
Dove Prism |
|
Ray Deviation (°) |
0 |
|
Image Orientation |
Left-Handed |
|
RoHS |
Compliant |
Description:
Dove prisms have an unusual and very interesting characteristic — if you look through the prism and rotate it around a longitudinal axis, the image rotates through twice the angle through which the dove prism itself rotates. For optimal peformance, use dove prisms with collimated light. The top surface of each Dove Prism is ground and the longest length (specified by dimension B) features an unbeveled sharp edge.
Competitive Advantage:
Dove prisms ,competitive price , good quality, delivery on time, providing perfect after-sales service, to provide customers with professional customized products of parameter. We will supply you with best solution.
