Hot And Cold Mirrors Optical Mirrors For Projection Systems Decreasing Heat
Hot And Cold Mirrors
Specifications:
|
Diameter (mm) |
12.5 |
||
|
Dimensional Tolerance (mm) |
±0.1 |
||
|
Thickness (mm) |
1.10 |
||
|
Angle of Incidence (°) |
0 |
||
|
Substrate |
BOROFLOAT |
||
|
Surface Accuracy (λ) |
4 - 6 |
||
|
Surface Quality |
60 - 40 |
||
|
Type |
Cold Mirror |
||
|
Wavelength Range (nm) |
425 - 1200 |
||
|
Coating |
0° Cold Mirror |
||
|
Coating Specification |
Ravg>90% @ 425 - 675nmRavg>85% @ 800 - 1200nm |
||
|
RoHS |
Compliant |
||
|
Diameter (mm) |
25.0 |
||
|
Diameter Tolerance (mm) |
±0.1 |
||
|
Thickness (mm) |
3.3 |
||
|
Substrate |
BOROFLOAT |
||
|
Angle of Incidence (°) |
0 |
||
|
Transmission (%) |
>92, 425 - 675nm |
||
|
Reflection (%) |
>95, 750 - 1150nm |
||
|
Surface Accuracy (λ) |
4 - 6 |
||
|
Surface Quality |
60 - 40 |
||
|
Wavelength Range (nm) |
425 - 1150 |
||
|
Type |
Hot Mirror |
||
|
Coating |
0° Hot Mirror |
||
|
Coating Specification |
Surface 1: 0° Hot Mirror |
||
|
RoHS |
Compliant |
||
Description:
These 0° and 45° angle of incidence Hot Mirrors are perfect for decreasing the undesirable heat caused by infrared radiation. A multilayer dielectric coating transmits 80% of visible light while reflecting over 90% of the NIR and IR, making them ideal for projection systems where heat build-up can lead to system damage. Made of BOROFLOAT glass, these hot mirrors can be cut to the desired size for any application.
These 0° and 45° angle of incidence Cold Mirrors are ideal for decreasing the undesirable heat caused by infrared radiation. A multilayer dielectric coating reflects 90% of visible light while transmitting over 80% of the NIR and IR. Cold Mirrors will function satisfactorily, and are resistant to damage, from ambient temperatures of -45°C to +232°C, ideal for projection systems where heat build-up can lead to system damage. Made of BOROFLOAT glass, these Cold Mirrors can be cut to the desired size for any application.
