Gr2 Seamless Titanium Tube Bright , Titanium Heat Exchanger Pipe
Quick Details :
GR2 seamless titanium tube
(1).Material:GR1,GR2,GR3,GR5,GR7,GR9,GR10
(2).Standard:ASTM B-337 338
(3).Surface:bright and smooth
Description:
1.Material:GR1,GR2,GR3,GR5,GR7,GR9,GR10
2. Standard: ASTM B338/B3372. Material: Gr1,Gr2,Gr3,Gr4,Gr5,Gr7,Gr9,Gr10
3.dimension; 5-110*1.0-4.5*2000-16460(seamless)
110*1.0-8*1000-2000(welded)
150-400*1.0-20*500-3000(seamless)
4.Manufacture techniques:cold rolling,welded
5 Condition:M
6.The Main Products
1) High precision seamless titanium tube for Medical and pharmaceutical
2) High precision seamless titanium tube for electric heating tube
3) High precision seamless titanium tube for aviation
4) Seamless titanium tube for air conditioner
5) Seamless titanium tube for Coastal power station ,nuclear power plant, Seawater desalination condenser and Heat exchanger
7.Chemical requirements
|
|
N |
C |
H |
Fe |
O |
Al |
V |
Pa |
Mo |
Ni |
Ti |
|
Gr 1 |
0.03 |
0.08 |
0.015 |
0.20 |
0.18 |
/ |
/ |
/ |
/ |
/ |
bal |
|
Gr 2 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/ |
/ |
/ |
bal |
|
Gr 3 |
0.05 |
0.08 |
0.015 |
0.30 |
0.35 |
/ |
/ |
/ |
/ |
/ |
bal |
|
Gr 5 |
0.05 |
0.08 |
0.015 |
0.40 |
0.20 |
5.5~6.75 |
3.5~4.5 |
/ |
/ |
/ |
bal |
|
Gr 7 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
0.12~0.25 |
/ |
/ |
bal |
|
Gr 9 |
0.03 |
0.08 |
0.015 |
0.25 |
0.15 |
2.5~3.5 |
2.0~3.0 |
/ |
/ |
/ |
bal |
|
Gr12 |
0.03 |
0.08 |
0.015 |
0.30 |
0.25 |
/ |
/ |
/ |
0.2~0.4 |
0.6~0.9 |
bal |
8.Tensile requirements
|
Grade |
Tensile strength(min) |
Yield strength(min) |
Elongation (%) |
||
|
ksi |
MPa |
ksi |
MPa |
||
|
Grade1 |
35 |
240 |
20 |
138 |
24 |
|
Grade 2 |
50 |
345 |
40 |
275 |
20 |
|
Grade 3 |
65 |
450 |
55 |
380 |
18 |
|
Grade 5 |
130 |
895 |
120 |
828 |
10 |
|
Grade 7 |
50 |
345 |
40 |
275 |
20 |
|
Grade 9 |
90 |
620 |
70 |
438 |
15 |
|
Grade 12 |
70 |
438 |
50 |
345 |
18 |
With advanced technology, high quality products, satisfied service, our General Manager along with
all staff welcome you come to establish long-term business cooperation relationships.
Applications:
(1) Shell and tube heat exchanger, condenser etc.
(2) Environmental protection equipment, cooling tube, titanium heat pipe, petroleum pipeline,
Sea farming, Fluid Transportation Piping, electroplating equipment.
(3) Bicycle frame, rings and other industries.
Specifications:
<
| Titanium Tube | ||
| Material | titanium and titanium alloy | |
| Grade | Gr1,Gr2,Gr3,Gr4,Gr5,Gr6,Gr7,Gr9,Gr10,Gr11,Gr12,BT1-00,BT1-0 | |
| Technology | Out Diameter (mm) | Wall Thickness(mm) |
| Standard | ||
| 3~5 | 0.2,0.3,0.5,0.6 | |
| >5~10 | 0.3, 0.5,0.6,0.8,1.0,1.25 | |
| ASTM B338, | >10~15 | 0.5,0.6,0.8,1.0,1.25,1.5, 2.0 |
| >20~30 | 0.6,0.8,1.0,1.25,1.5,2.0,2.5,3.0 | |
| ASME SB338, | >30~40 | 1.0,1.25,1.5, 2.0,2.5,3.0,3.5 |
| >40~50 | 1.25,1.5, 2.0,2.5,3.0,3.5 | |
| ASTM B337 | >50~60 | 1.5, 2.0,2.5,3.0,3.5,4.0 |
| >60~80 | 1.5, 2.0,2.5,3.0,3.5,4.0,4.5 | |
| ASTM B861 | >80~114 | 2.5,3.0,3.5,4.0,4.5 |
| 16 | 0.5,0.6,0.8,1.0 | |
| 19 | 0.5,0.6,0.8,1.0,1.25 | |
| 25,27 | 0.5,0.6,0.8,1.0,1.25,1.5 | |
| 31,32,33 | 0.8,1.0,1.25,1.5, 2.0 | |
| 38 | 1.5, 2.0,2.5 | |
| 50 | 2.0,2.5 | |
| 63 | 2.0,2.5 | |
| 6~10 | 0.5,0.6,0.8,1.0,1.25 | |
| >10~15 | 0.5,0.6,0.8,1.0,1.25,1.5 | |
| >15~20 | 0.5,0.6,0.8,1.0,1.25,1.5,2.0 | |
| >20~30 | 0.5,0.6,0.8,1.0,1.25,1.5,2.0 | |
| Specification | Φ3~114mm, δ 0.2~4.5mm,L<8000mm,or according to client's demand | |
| Variety | Seamless | |
| Delivery State | Annealing state(M) | |
| Features | u Toughness, light weight, | |
| u High property of acid and alkali resistance, | ||
| u Bear high & low temperature, etc. | ||
| Applications | l Different fields: | |
| Aerospace,Defence,Energy,Medical,Performance Sports | ||
| l Fabricated Products: | ||
| Heat exchanger, Condenser, Evaporimeter, Conduit pipe,HydraulicTube, | ||
| Horn Tube, Capillary Tube, Boiler Tube, Precision Tube, IBR Tube | ||
| Anode/Cathode/Celll components etc. | ||
| Packing | plywood case as outside, or according to client's demand | |
<
Quality Guarantee:
(1) Main quality indicators:Chemical composition, mechanical property, tolerance
(2) With advanced technology & equipment, abundant experiences and skilled workers,we process titanium material according to China or International standard
(3)With own R&D, Produce, Process and Sales system, we are struggle for supply the most excellent product, the lowest price and the best service for each client.
(4)Mill Test Certificate provide before deivery to ensure the quality if you need.
(5)Warmly welcome you send inquiry to us!
