Economical P25 Stadium Perimeter LED Display Signs Flexible

Get Latest Price

Min. Order:: 1

Min. Order:: 1

Delivery Time:: 30 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen, China

Product Description

Economical P25 Stadium Perimeter LED Display Signs Flexible , Waterproof 200mm * 200mm

Quick Detail:

1. 28°support adjustable

2. Soft mark used

3. High Brightness more than 8000cd/sqm

4. Long lifespan up to 100,000 hours

5. Waterproof and 2 years warranty

6. Support any format of video, RF, S-Video, RGB, RGBHV, YUV, YC, COMPOSITION

Description:

1. Economical

Used for playing image and text etc and it still can meet clients’ requirement for logos, advertisement play

etc.

2. Soft Mask Applied

Soft mask design delivers good protection to the players and also decreases damage to LEDs.

3. Quick rigging system

Quick rigging system makes the installation and dismantle be easier and faster.

4. High Quality and Reliability

Our many outdoor screens have been used by our clients around the world for 3-5 years and rarely

product issues are called.

5. Waterproof and 2 Year Warranty

Water Proof IP65 and 2 year warranty. LED display can work in all-weather condition very well.

6. CE & Rohs Certified

Applications:

Stadium inside and outside such as football pitch, baseball, basketball etc

Specifications:

1. Outdoor LED Display Technical Parameter

Model No.	NS-OR-DD-P25
Pixel Pitch	25mm
Module Size	200mm*200mm
Module Resolution (W*H)	8dots*8 dots
Pixel Density	1600 dots/ ㎡
LED Type	5mm Oval Lamp
Pixel Configuration	1R1G1B
Wavelength (R.G.B)	R:625±2nm G:525±2nm B:470±2nm
Drive Mode	Dynamic 1/4 Duty Constant Current
Cabinet Size	1000×1000×150mm
Cabinet Resolution	40dots×40dots
Brightness	≥5500cd/㎡
Contrast	≥4000:1
Viewing Angle	110°(Horizontal )/45°(Vertical )
Best Viewing Distance	10m-300m
Grey Scale	10bits/1024levels
Color Capability	16777216
Color Temperature	5000-9300K
Maximum Power Consumption	1000 W/m2
Average Power Consumption	350 W/m2
Working Voltage	AC 220V/110V s±15% 50-60 HZ
Frame Frequency	60-85 HZ
Refresh Frequency	240 - 1000HZ
Brightness Correction	Pixel, Module, Cabinet Correction
Operating Temperature	Static:-40℃~+85℃Working:-20~+65℃
Operating Humidity	10-90% RH
LED Lifespan	100,000 hours
MTBF	≥50,000 hours
Computer Operation System	Win 98/ Win XP/ Win 2000
Video Signal Input	RF,S-Video, RGB,RGBHV,YUV,YC,VGA, DVI, HDMI, SDI,HD-SDI ,Composite
Video Signal Output	RF, S-Video, RGB, RGBHV, YUV, YC etc.
Graphics Card	DVI Graphics Card
Control Distance	LINSN / NOVA / DB-STAR
Software	LED studio 10.0
Waterproof Level	IP65(Front Side), IP54 (Back Side
Installation	Wall mount, hung and stand structure
Out of Control Rate	0.01 %

2. Outdoor LED Display Module

Module Size (W*H)	200mm*200mm	Pixel Configuration	1R1G1B
Pixel Pitch	25mm	Resolution (W*H)	8 dots*8dots
Pixel Density	1600 dots/㎡	LED Type	5mm Oval Lamp

3. Outdoor LED Display Cabinet

Cabinet Size (W*H)	1000mm*1000mm	Module Qty	25 pcs
Cabinet Resolution (W*H)	40 dots*40 dots	Cabinet Pixel	1600
Weight	50 kg/ Cabinet	Area	1㎡
Average Power Consumption	300w/㎡	Max Consumption	1000 W/m2

4. Methods for Quality Assurance

a. Aging

1. 100% fully test

2. Condition: 72 hours with 256 grey level

b. Vibration Testing

Condition: 3-5 mins up and down in 5mm range

5. Factory Equipment

Wave Soldering Conveyor, PC Console, Wave Soldering Machine,
Automatic Glue- pouring Machine, Solder Paste Printing Machine,
Reflow Soldering Machine, Automatic Solder Paste Printing Machine,
Withstand Voltage Tester, Ground Resistance Tester,
Medium-speed Automatic SMT Machine, Super Mute Terminal Machine,
Automatic Wire Stripping Machine, Automatic Optical Inspection (AOI) Equipement.

6. Package

Flight case and Fumigation-Free wooden case

7. Control System Connection

8. Competitive Advantage:

1. 24/7 Online support service

2. Free onsite maintenance / Year

3. Solution design

4. Free online training any time

5. High quality raw material used like neutrik flight connector, MBI IC etc.
