GOOD RIGIDITY OF PNEUMATIC SHUT OFF VALVE
Quick Detail:
|
Name |
Pneumatic cut-off valve |
Brand Name |
ROSNM |
|
Color |
As your request |
Certificate |
ISO9001 |
|
Warranty |
1 year |
Place of Origin |
RUIAN |
Description:
pneumatic two-place cutting valves is one of the automatic units during industrial production in according with the signal of the meter to open or close flowing agency it can satisfy the requirement with pressure , temperature ,flowing volume ,etc technical parameter. Series of ZSC-PRⅢ pneumatic woe-place cutting valve in our company with small volume sealing and reliability LONG life ease of maintenance and explosion-proof ,etc merits .So it is used widely in self-control and remote system of various industrial productions when closing no permission to leak ,especially suitable for various specifications type vulcanized machine. Product executive standard:HG/T3236-2006 Patent No.:200920219873.6
Applications:
Used for used widely in self-control and remote system of various industrial productions when closing no permission to leak ,especially suitable for various specifications type vulcanized machine
Specifications
|
Model |
Pneumatic cut-off valve |
|
||||||||||||||
|
Nominal pressure |
1.6 4.0MPa |
|
||||||||||||||
|
Nominal diameter |
15 20 25 32 40 50 80 |
|
||||||||||||||
|
Signal pressure |
0.35MPa |
|
||||||||||||||
|
Work temperature |
-20~+300℃ |
|
||||||||||||||
|
Work medium |
Nitrogen Liquid Steam gas |
|
||||||||||||||
|
|
THREE position FLANGE TYPE OVERALL DIMENSIONS |
|||||||||||||||
|
|
Nominal pressure |
1.6 4.0Mpa |
||||||||||||||
|
|
DN |
L |
D |
SIZE |
H1 |
H2 |
H |
ΦA |
||||||||
|
|
D1 |
D2 |
D6 |
b |
f |
|
||||||||||
|
|
N-Φd |
|||||||||||||||
|
|
air-to-open |
|||||||||||||||
|
|
15 |
146 |
95 |
70 |
52 |
46 |
14 |
2 |
4 |
14 |
88 |
199 |
287 |
93 |
||
|
|
20 |
185 |
115 |
85 |
65 |
58 |
16 |
2 |
4 |
14 |
109 |
263 |
372 |
125 |
||
|
|
25 |
185 |
115 |
85 |
65 |
58 |
16 |
2 |
4 |
14 |
109 |
263 |
372 |
125 |
||
|
|
32 |
195 |
145 |
110 |
85 |
76 |
18 |
2 |
4 |
18 |
120 |
294 |
414 |
162 |
||
|
|
40 |
195 |
145 |
110 |
85 |
76 |
18 |
2 |
4 |
18 |
120 |
294 |
414 |
162 |
||
|
|
50 |
220 |
160 |
125 |
100 |
88 |
20 |
2 |
4 |
18 |
131 |
330 |
461 |
203 |
||
|
|
AIR-TO-CLOSE |
|||||||||||||||
|
|
20 |
185 |
115 |
85 |
65 |
58 |
16 |
2 |
4 |
14 |
109 |
321 |
430 |
125 |
||
|
|
25 |
185 |
115 |
85 |
65 |
58 |
16 |
2 |
4 |
14 |
109 |
321 |
430 |
125 |
||
|
|
32 |
195 |
145 |
110 |
85 |
76 |
18 |
2 |
4 |
18 |
120 |
357 |
477 |
162 |
||
|
|
40 |
195 |
145 |
110 |
85 |
76 |
18 |
2 |
4 |
18 |
120 |
357 |
477 |
162 |
||
|
TWO position FLANGE TYPE OVERALL DIMENSIONS |
|||||||||||||
|
Nominal pressure |
1.6 4.0Mpa |
||||||||||||
|
DN |
L |
D |
SIZE |
H1 |
H2 |
H |
ΦA |
||||||
|
D1 |
D2 |
D6 |
b |
f |
|
||||||||
|
N-Φd |
|||||||||||||
|
air-to-open |
|||||||||||||
|
1"/2 |
98 |
1"/2 |
|
|
|
|
|
|
|
53 |
199 |
252 |
93 |
|
15 |
146 |
95 |
70 |
52 |
46 |
14 |
2 |
4 |
14 |
53 |
199 |
252 |
93 |
|
20 |
185 |
115 |
85 |
65 |
58 |
16 |
2 |
4 |
14 |
65 |
263 |
328 |
125 |
|
25 |
185 |
115 |
85 |
65 |
58 |
16 |
2 |
4 |
14 |
65 |
263 |
328 |
125 |
|
32 |
195 |
145 |
110 |
85 |
76 |
18 |
2 |
4 |
18 |
76 |
294 |
370 |
162 |
|
40 |
195 |
145 |
110 |
85 |
76 |
18 |
2 |
4 |
18 |
76 |
294 |
370 |
162 |
|
50 |
220 |
160 |
125 |
100 |
88 |
20 |
2 |
4 |
18 |
90 |
330 |
420 |
203 |
|
65 |
290 |
180 |
145 |
120 |
110 |
22 |
3 |
8 |
18 |
117 |
411 |
528 |
260 |
|
80 |
310 |
195 |
160 |
135 |
121 |
22 |
3 |
8 |
18 |
127 |
460 |
587 |
280 |
|
100 |
350 |
230 |
190 |
160 |
15 |
24 |
3 |
8 |
23 |
141 |
501 |
642 |
