Heavy Duty 250tons Pipe Welding Rotator , Self Aligning Rot

Heavy Duty 250tons Pipe Welding Rotator , Self Aligning Rotator

1. Description:

Automatic welding center is mainly composed of welding manipulator, floor turntable positioner and welding rotator. When working, the fist is to make piece on the floor turntable positioner and turn welding rotator to make the work-piece stay to weld by process requirements. Then make welding torch adjust to a certain welding position through kinds of movement of welding manipulator. At the last, start welding machine and rotate work-piece by positioner to realize automatic welding.

2. Specifications:

4. Competitive Advantage:

Self aligning rotator is composed of power rotator and idler rotator. Power rotator has advantage of driving rotator turning to make work-piece rotate. It has high load capacity, and the line speed meets the requirements of welding, adopting AC variable frequency speed regulation. Idler rotator is same as driven rotator, playing the supporting role but unpowered, and it turns by the work-piece friction. This equipment consists of power rotator and idler rotator. The tilt angle of roller group can be manual adjusted by screw. It has advantages of reliable quality, superior performance, simple operation etc.

The complete set of equipment adopts advanced trinity centralized control mode. It means that welding manipulator, welding positioner and functions of welding machine can be fused together organically to realize welding better. At the same time, it is also equipped with a remote control box which has all operation functions of this machine to operate conveniently.
