Hot Dip Galvanized Wire 2x1x1m PVC Coated Gabion Boxes Preventing Of Rock Breaking
1. Konson Galvanized Gabion:
Gabions are cages, cylinders, or boxes filled with soil or sand that are used in civil engineering, road building, and military applications. For erosion control caged riprap is used.For dams or foundation construction, cylindrical metal structures are used.
Konson Gabion box by CE certification and ISO9001, SGS, ASTMA97597, EN 10223 standard within SGS. We are certain that the quality is better than other suppliers and can meet you request.
2. Specification:
|
Opening(mm) |
Wire diameter (mm) |
Wire Diameter (PVC Coated)/ Inner/Outside(mm) |
Size(m) |
|
60x80 |
2.0-2.8 |
2.0/3.0-2.5/3.5 |
1x1x0.3 1x1x0.5 |
|
80x100 |
2.0-3.2 |
2.0/3.0-2.8/3.8 |
|
|
80x120 |
2.0-3.2 |
2.0/3.0-2.8/3.8 |
|
|
100x120 |
2.0-3.4 |
2.0/3.0-2.8/3.8 |
|
|
100x150 |
2.0-3.4 |
2.0/3.0-2.8/3.8 |
|
|
120x150 |
2.0-4.0 |
2.0/3.0-3.0/4.0 |
3. Details:
1.Certification:
ASTM A75-97, BS1052, EN-10223-3, YB/T4190-2009, ISO9001:2000, CE
2.Materials: Hot dip galvanized wire
Heavy zinc-coated wire(220-290g/m2 )
Pvc coated wire
Galfan wire
3.Coating: Zinc, PE, PVC, Zn-5-AL, Zn-10-Al
4.Gabion selvedge wire diameter: 2.2mm, 2.4mm, 2.7mm, 3mm, 3.4mm, 4mm
5.Gabion tie wire/lacing wire diameter: 2.2mm, 3%, 5%, 8% of weight
4. Application:
1.Control and guide of water or flood , Preventing of rock breaking , Keep off dust wall
2.Rock fall protection , Water and soil protection , Port project, roadway protection
3.Bridge protection , Strengthening structure of soil
4.Protection engineering of seaside area.
When requesting a quotation, please give me all the details:
Example:
|
Materials |
Hot dip galvanized wire |
|
Size of units (length x width x height) |
2x1x1m |
|
Quantity |
6000 units |
|
Opening mesh size |
80x100mm |
|
Type of coating |
PVC |
|
Mesh Diameter |
2.7-3.7mm |
|
Selvedge wire diameter |
3.0-4.0mm |
|
Tie wire/lacing wire diameter |
2.2-3.2mm |
|
Other |
As your request |
Why always choose KONSON?
+ The earliest manufacturer of Gabion machine in China.
+ We have experience of export business for more than 15 years.
+ The finished products can meet international standard ASTM , BS, EN and pass ISO,SGS quality certificate system.
+ Complete material testing system and QC system.
+ Experienced staffs, the fastest delivery time.
+ Best service (Any enquiry will be replied within 24 hours). Thanks for your reading!
