Full Color Easy Customization LED Scrolling Message Board
Quick Detail:
1. Name:IDsn 7C
2. Module Size:500*500*45mm
3. Brightness:>1200cd/m2
4. LED Chip:Epistar
5. Grey Scale:16bit
6. Cabinet Matericval:Carbon Fiber
Description:
1. Carbon Fiber materials for super light and thin structure.
2. Indoor LED: deepest blackness levels and light absorbing techniques
3. Angled edge structure for max 90 degree curved assembly
4. Glux fast-assembly mechanism= compatible to all other glux LED Screens
5. Module measurements:0.5*0.5m
Applications:
Glux IDsn series suit for stage background, bar and mansion studio, entertainment venuese
Specifications:
|
Glux LED Display IDsn Series |
IDsn 3C |
IDsn 6C |
IDsn 7C |
|
Pixel Pitch(mm) |
3.9 |
6.2 |
7.8 |
|
Pixel Density(dots/m2) |
65536 |
25600 |
16384 |
|
Brightness(cd/m2) |
2000 |
>1200 |
>1200 |
|
Color Temperature(after calibration)K |
6500 |
6500 |
6500 |
|
Module Size(W*H*D)(mm) |
500*500*45 |
500*500*45 |
500*500*45 |
|
Weight(kg/Panel) |
3.3 |
3.3 |
3.3 |
|
Weight(kg/m2) |
13.2 |
13.2 |
13.2 |
|
LED Type |
2724 Black |
3528 Black |
3528 Black |
|
LED Chip |
Epistar |
Epistar |
Epistar |
|
Horizontal/Vertical Viewing Angle(º) |
H160º/V160º |
H160º/V160º |
H160º/V160º |
|
Recommended Viewing Distance(m) |
4 |
6 |
8 |
|
Contrast |
3500:1 |
2000:1 |
2000:1 |
|
Refresh Rate(Hz) |
1200 |
2000 |
2500 |
|
Grey Scale(bit) |
16 |
16 |
16 |
|
Frame Rate(Hz) |
50/60 |
50/60 |
50/60 |
|
Life Time(H) |
≥75000 |
≥75000 |
≥75000 |
|
Protection |
Indoor |
Indoor |
Indoor |
|
Power Supply |
Singular Power Supply |
Singular Power Supply |
Singular Power Supply |
|
Max Power Consumption(W/M2) |
540 |
540 |
540 |
|
Avr Power Consumption (W/M2) |
180 |
180 |
180 |
|
Working Temperature |
-25-60℃ |
-25-60℃ |
-25-60℃ |
|
Working Humidity |
10%-95% |
10%-95% |
10%-95% |
|
Driving Method |
1/8 |
1/5 |
1/4 |
|
Driving Chip |
MBI5041 |
MBI5041 |
MBI5041 |
|
Cabinet Material |
Carbon fiber |
Carbon fiber |
Carbon fiber |
|
Control Input |
DVI/HDMI/HDSDI |
DVI/HDMI/HDSDI |
DVI/HDMI/HDSDI |
|
Certification |
CE/FCC/TUV |
CE/FCC/TUV |
CE/FCC/TUV |
|
Max Hanging(Vertical) |
1400kg |
1400kg |
1400kg |
