Dreambox 800 HD PVR DM800HD Cable Receiver Support CA VFD L
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|
SPECIFICATIONS:
300MHz MIPS processor
Single-EPG (Electronic Program Guide):sortable by data or alphabetically
Automatic search for additional air dates of a show and easy recording them by timer
Multi-EPG:graphically and text-based
Timeshift
List of recordings:sortable by date or alphabetically and free choice of different views
Timer programming manually or by EPG
Individually configurable timers,e,g,single or recurring timers
DiSEqC 1.0/1.1/1.2/1.3(USALS)
Channel change in less than a second
Start wizard for initial setup
Pre-intalled service list for DVB-S
Support of favorite lists
l Full automatic channel scan
l DVB/teletext with level 2.5 support
l Easy expansion of base function with the use of plugins
l MP3 playback
l Skinable OSD in many languages
l Remote controllable via Web-interface and streaming of the TV-/Radio stations to any PC connected to the box through network
l Linux operating system
l A smart card reader
l MPEG2/H.264 hardware decoder
l Pluggable tuner modules
l LED panel with instructions
l 64MFlash 256MRam
l Built-in 2.5-inch hard drive or eSATA
l 10/100M Ethernet port
l Two USB2.0 interface
l V24/RS232 interface
Technical parameter:
DBS-Tuner without DVB-S2
l European plug interface
l Frequency Range 950 -2150MHz
l Demodulation DVB-S(QPSK)
l Signal level -65dBm -25dBm
l DBS-Tuner Input Connector F-Type female
l Input impedance 75ohm
l Loop through interner loop trough
l AFC+/-Mhz
l DVB-S: Viterbirates:1/2, 2/3, 3/4,5/6,7/8,automatical adjustment(k=7)
l Roll-off Factor 35%
Video decoder:
l Video compression MPEG-2 and MPEG-1 compatible,H.264
l Video Formats 4:3 / 16:9
l Letterbox percolating for 4:3 TV-Device
Audio decoder:
l Audio compression MPEG-1&MPEG-2 layer I and II
l Audio Mode Stereo ,Dolby Digital
l Frequency:32kHz,44.1kHz,48KHz,16kHz,22.05kHz,24kHz
Analog output:
l Output level L/R 0.5 Vss on 600Ohm
l THD>60dB(1kH)
l Crosstalk<-65dB
Physical specification:
l Ambient Temperature +15C...+35C
l Humidity<80%
l Size(WxDxH):374mmx230mmx75mm
l Weight:2.2kg without HDD
