AWWA C504 Manual Large Diameter Butterfly Valves For Water
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Tianjin ,China |
|---|
AWWA C504 Manual Large Diameter Butterfly Valves For Water / Steam 2 Inch 4" 6"
Quick Details
| Standard or Nonstandard: | Standard | Structure: | Butterfly | Pressure: | Low Pressure |
| Power: | Manual | Material: | Casting | Temperature of Media: | Low Temperature |
| Media: | Water | Port Size: | DN50-DN1200 | Place of Origin: | Tianjin China (Mainland) |
| Model Number: | DIN | Brand Name: | TST |
Packaging & Delivery
| Packaging Detail: | seaworthy wooden cases |
| Delivery Detail: | 45 DAYS |
Specifications
1, High quality and competitive price
2, FF: API 609, ISO 5752, BS 5155, AWWA C504
3, EN1092 flange
4, ISO 9001, CE Approved
Face to Face: API 609 Table 2C(Short pattern)
ISO 5752 Series 13
BS 5155 Series 2 (Short)
AWWA C504(Short)
End Connection: EN1092-2 PN10/PN16
Top Flange: ISO 5211/1
Standard Features:
* The heavy duty double flanged design is suitable for high pressure loading and is excellently suited for use in shipbuilding,waterworks,iron&steel industry and power stations.
* ISO 5211 top flange is provided on every valve for easy actuation
* One-Piece shaft design,blow-out proof,ensures positive disc positioning and accurate flow control
* Disc edge is machined and polished 360º to assure low friction,which results in low operating torque plus increased seat life.
* Precision taper pins, vibration-proof, ensure positive shaft-disc connection.
* The resilient seat is fully vulcanized in the body, which isolates the body components from the media and provides the primary shaft seal.
* Abosolutely tight shut-off(no visible leakage at the naked eyes) in either flow direction.
* Can be installed in any desired direction
Competitive Advantage:
1. Hole bolts or unilateral bolt to use, easy to replace and install
2. Valve shaft and valve plate pin or no pin connection, to complete the open or closed
