CE Brass Water Fountain Equipment Fountain Gate Valve SS304
- Min. Order:
- 1
- Min. Order:
- 1
- Delivery Time:
- 30 Days
Quantity:
Your message must be between 20 to 2000 characters
Contact NowBasic Info
Basic Info
| Place of Origin: | Guangzhou, China |
|---|
Product Description
Product Description
CE Brass Water Fountain Equipment Gate Valve SS304 NPT Thread Female
Description:
1) Investment Casting Body
2) Working pressure 800/1000 PSI For W.O.G
3) Pure Teflon Seals And Seats
Advantage:
1. Wear resistance
2. Good sealing performance
3. Light switch
4. Long service life
Features:
Technical standard
1. Norminal pressure: 1.6MPa
2. Working medium: Water, non-causticity liquid, saturated steam
3. Working temperature: -20° C≤ T≤ 120° C
4. Pipe thread to ISO 228
Dimensions:
| Size | 1/2" | 3/4" | 1" | 1-1/4" | 1-1/2" | 2" | 2-1/2" | 3" |
| L | 55 | 60 | 65 | 75 | 85 | 95 | 115 | 130 |
| H | 96 | 105 | 115 | 130 | 145 | 170 | 210 | 236 |
| φE | 70 | 70 | 80 | 80 | 95 | 95 | 125 | 125 |
Parts details:
| No. | Part name | Material |
| 1 | Body | Brass |
| 2 | Disc | Brass |
| 3 | Stem | Brass |
| 4 | Body gasket | Brass |
| 5 | Cap | CF8M |
| 6 | Stem packing | PTFE |
| 7 | Stop nut | Brass |
| 8 | Handle | Cast Iron |
| 9 | Stem nut | Brass |
| 10 | Washer | Brass |
| 11 | Stop gasket | Brass |
| 12 | Gland | Brass |
