Basic Info

Place of Origin:	China

Product Description

LCD 50Hz / 60Hz High Frequency Online UPS 3KVA/2.1KW For Office

Specifications:
1.Online UPS HP9116C 3KVA/2.1KW
2.High Frequency UPS
3.UPS Systems
4.UPS

Features:
1.Large Blue Back Light LCD for Detailed Real-Time UPS Status Display
2.Microprocessor control guarantees high reliability
3.Comprehensive Self-Protection Design
4.Audible Alarm Mute
5.Cold Start Funcition
6.Auto Self-Testing System whileTurning on UPS
7.Wide Input Voltage Range

TECHNICAL SPECIFICATIONS

Product Series		Online ups with large LCD Display (1-3kva)
Model		HP9116C 1KT	HP9116C 1KT-XL	HP9116C 2KT	HP9116C 2KT-XL	HP9116C 3KT	HP9116C 3KT-XL
Capacity	VA/W	1000VA/800W		2000VA/1600W		3000VA/2400W
Input	Low Line Transfer	160VAC/140VAC/120VAC/110VAC ± 5VAC
	Low Line Comeback	175VAC ± 5VAC
	High Line Transfer	300VAC ± 5VAC
	High Line Comeback	285VAC ± 5VAC
	Frequency Range	50Hz: 46-54Hz; 60Hz: 56-64Hz
	Phase	Single phase with groud
	Power Factor	≥0.95
Output	Voltage	220/230/240VAC
	Voltage Regulation	± 2%
	Frequency	Synchronization range (line mode);50 or 60 × (1±0. 2%) Hz (Battery mode)
	Current Crest Radio	3:1
	Voltage Distortion	≤3% THD (Linear Load)		≤4% THD (Linear Load)
		≤4% THD (Linear Load)		≤4% THD (Linear Load)
	Waveform	Pure Sinewave
Battery	Type and Number	12V/7AH 3	Depending on the capacity of external batteries	12V/7AH 8	Depending on the capacity of external batteries	12V/7AH 8	Depending on the capacity of external batteries
	Back up Time (full load)	5 minutes		9 minutes		5 minutes
	Recharge Time	5 hours to 90%		5 hours to 90%		5 hours to 90%
	Charging Current	1.0A	8A	1.0A	8A	1.0A	8A
	Changing Voltage	41.1VDC ± 0.6V		110VDC ± 0.4V		110VDC ± 0.4V
Transfer Time	AC to DC	Zero
	Inverter to Bypass	2.5ms (Typical)
Indicator	Staus	Load Level / Battery Level / Battery Mode / AC Mode / Bypass Mode / Fault
Audible alarm	Overload	Sounding twice every second
	Low Battery	Sounding every second
	Fault	Continuously Sounding
	Battery Mode	Sounding every 4 seconds
Physical	UPS Case	482.6×450×87 (w.battery)		482.6×450×87 (w.battery)
	Dimension D× W× H(mm)	400×145×220		46×192×340
	Net Wight(Kg)	14	7	34.5	15	35.5	16
Environment	Operating Environment	0-40°C ,20-90% relative humidity (non-condensing)
	Noise Level	Less than 45dB@1 Meter		Less than 50dB@1 Meter
Interface	Smart RS232	Software Support Windows family,Linux,Sun Solaris,IBM Aix,Compaq True64,SGI IRIX,FreeBSD,HP-UX and MAC
	SNMP (Option)	Power management from SNMP manager and web browse
	USB Option	Support Windows family and MAC OS
