High Precision Thrust ball bearing 51148,51152,51156,51160,51164,51168,51172,51180
Quick Detail:
Product name: Thrust ball bearing
Model number: 51148,51152,51156,51160,51164,51168,51172,51180
Number of row : single row
Precision rating:P0 P6 P5
Cage:Carton steel,brass,Nylon,Ceramic
Material:Gcr15,Stainless steel,Carton steel,Plastic,Ceramic
Description:
Thrust ball bearings are composed of Seat ring, shaft and cage assemblies,and they can be separated.They adopt the design that can withstand thrust load when at high speeds .The bearings can accommodate axial loads, but unable to bear the radial load.
Applications:
The bearings only bear a part of the axial load or low speed, such as crane hook, vertical pumps, vertical centrifuge, jack, low speed reducer.
Specifications:
| Bearing No | Boundary dimensions (mm) | Weight (kg) | ||
| d | D | T | ||
| 51148 | 240 | 300 | 45 | 7.49 |
| 51152 | 260 | 320 | 45 | 8.1 |
| 51156 | 280 | 250 | 53 | 12.3 |
| 51160 | 300 | 380 | 62 | 17.5 |
| 51164 | 320 | 400 | 63 | 18.76 |
| 51168 | 340 | 420 | 64 | 19.76 |
| 51172 | 360 | 440 | 65 | 22 |
| 51180 | 400 | 480 | 65 | 23.8 |
Competitive advantages:
Our company product and export bearings for 20years,so we have a deep knowledge of bearing.we can guarantee the quality and the price ,and we ensure our production can meet your requirement. In addition ,we can manufacture the production according your requirement.
Main production:
Deep Groove Ball Bearing / Angular Contact Ball Bearing/ Taper Roller Bearing/ Spherical Roller Bearing /Cylindrical Roller Bearing / Thrust Ball Bearing /Thrust Roller Bearing / Self-aligning ball bearing/ Self-aligning roller bearing/ Pillow Block Bearing / Needle Roller Bearing /Tracking Roller Bearing/ Auto Bearing Etc.
