Woodgrain Sectional Insulated Garage Doors Automatic With F

Woodgrain Sectional Insulated Garage Doors Automatic With Finger Protection Panel

Quick Detail:

1. Sectional garage door with cassette woodgrain design

2. Energy saving & thermal insulation

3. With PU foam inside, superior R-value

4. Steel-foaming-Steel, sandwich construction

5. Rust-resistant and color retention

6. Hardware system of EU safety standard

7. Many trend colors offered at favorable prices

8. Reliable performance & years of service

Description:

1. Material: galvanized steel with Polyurethane insulation
2. Steel thickness: 0.35mm, 0.45mm ( white color only)
3. Panel thickness:40 mm
4. Foaming material: polyurethane
5. Density of foam: 43-45kg/m³
6. Panel type: Finger protection panel & non-finger protection panel
7. Construction: sandwich contraction
8. Panel width: 440-550mm
9. Max panel length: 12m
10. Weight: 8.5kg/m²
11. Surface finishes: wood grain, orange peel, flush
12. Panel design: rectangle woodgrain design
13. Standard package: carton box with film for 4 or 5 pieces of panel, usually as full set of garage door panel
14. Normal color: Off white RAL9016

Normal Solid colors: Brown RAL8014, Anthracite grey RAL7016, Silver RAL9006, Light beige RAL1019, Ebony RAL9004, Red RAL3000, Blue RAL5015;

Timber color: Mahogany, Gold oak, Dark oak, Black walnut

1. Single track and double track:

Single track only: 1 pair vertical track, 1 pair horizontal track, needs min headroom 350mm

Double track only: 1 pair vertical track, 1 pair horizontal track, 1 pair LHR horizontal track, needs min headroom 150mm

1. Full set of hardware: Torsion spring, Hinges, Cable drum with cable, Central bracket with bearing, 1'' tube shaft, Mounting brackets and other accessories for a complete set
2. Emergency lock for manual operation when power off
3. Residential garage door opener: 800N, 1000N, 1200N, 1500N

Applications:

The panel can be inserted the windows to allow daylight to enter your garage, provide it with further uses, e.g. as a workshop or hobby room.

A sectional door leaf glides vertically upwards under the garage ceiling. This provides you with more space than with a convenient up-and-over door. Please kindly see attached drawing of garage door.

Specifications:

Competitive Advantage:

1. Low MOQ: One set is available for checking our quality first conveniently.

2. Good Quality: Your client satisfied on our quality. You can get good reputation from your market and obtain more orders.

3. Good Service: Our professional service before and after sale.

4. The reasonable price

5. Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).

6. OEM is welcome

7. Rot-proof rubber seal for maximum light and air sealing between the sections.

8. Energy saving heat insulation due to high-strength PU rigid foam. The special foam meets the high quality requirements of industrial doors.

9. High-level resistance to bending and twisting. Secures garages against burglars and makes your door wind and weather proof.

10. Robust surface, easy to clean, the finished surface is extremely robust and easy to maintain.
