Product Description

Lasenic® PS Properties Data Sheet
①Raw material description
Standard Grade:	Extrusion grade		Appearance color:	┄
Application	Processing materials,rod,sheet,board,tube.Used in artisan market,daily cecorate,illumination indication and package
Remarks:	Charactors: easy for machine shaping,transparent,cheap,rigidity,insulative,easy printing

②Raw material technical datasheet
Property item		Test conditions	Testing method	Testing data	Unit
I.Physical property
Density		23°C	ASTM D792	1.05	g/cm3
Shrinkage		┄	ASTM D955	0.3~0.6	%
Water absorption		┄	ASTM D570	<0.1	%
Flammability class		┄	UL94	HB	Class

Ⅱ.Mechanical property
Tensile strength		┄	ASTM D638	50	MPa
Elongation at break		┄	ASTM D638	3	%
Flexural strength		┄	ASTM D790	105	MPa
Flexural modulus		┄	ASTM D790	3200	MPa
Compressive strength		┄	ASTM D790	115	MPa
Hardness-Shore D		┄	ASTM D785	65~90	M(Scale)
Cantilever beam tensile strength(Unnotched)		23°C	ASTM D256	10	KJ/m2

Ⅲ.Thermal property
Thermal deformation temperature		anneal	ASTM D648	88	℃
Max. working temperature( short time)		┄	UL746B	80	℃
Max. working temperature(long time)		┄	UL746B	60~75	℃
Vicat softening temperature		B/50 (50N, 50oC/h)	ASTM D1525	101	℃
Brittle temperature		┄	ASTM D746	-30	℃
Thermal conductivity		23°C	ASTM C177	0.14	W/(m*K)
Coefficient linear thermal expansion		┄	ASTM D696	8	10-5K-1

Ⅳ.Electrical property
Dielectric constant		1 MHz	IEC 60250	2.40~2.65	106Hz
Dielectric loss angle tangent		1 MHz	IEC 60250	(1~2)×10-4	106Hz
Dielectric strength		┄	IEC 60243	20~28	kV/mm
Volume resistivity		┄	IEC 60093	＞1017	Ω * cm
Surface resistivity		┄	IEC 60093	＞1013	Ω
Electric arc resistance		┄	IEC 112	60~135	sec

NOTE: 1 g/cm3 = 1,000 kg/m3, 1 Mpa = 1 N/mm2, 1kV/mm = 1 MV/m
Statement:
NOTE: The information contained herein are typical values intended for reference and comparison purposes only. They should NOT be used as a basis for design specifications or quality control. Quanda will not provide any legally binding guarantee of certain properties, or any suitability.
