Soundboss 1R1G1B DIP P10 outdoor led illumination panel dis

Get Latest Price

Min. Order:: 1

Min. Order:: 1

Delivery Time:: 30 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Shenzhen China

Product Description

Soundboss 1R1G1B DIP P10 outdoor led illumination panel display screen

2011 Asian cup LED supplier

1. 36 months warranty. And life long free tech-support

2. CE and RoHS approval

3. Excellent contrast ratio, high resolution /high definition

4. High brightness and perfect uniformity

5.Waterproof IP65

Application:

Our products have been widely used in venues as banks, stock exchange centers, schools, telecommunications, customs, stadiums, studio, shopping malls, railways, airports, harbors, city squares, courts, schools, restaurants etc;

Advantage:

1. Wide application & short ROI time:

Commercial advertising, Stadium perimeter, mobile media, shopping mall, bank & stock exchange, train & bus station, air port,

2. High Contrast ratio: 4000:1

This is a very high level to ensure a vivid image of our LED display screen system.

3. First-class LED chip:

Supplied by high strictly selected LED chip to ensure the long life time and high brightness of our LED display screen system

4. Clear vivid image quality:

Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your investment.

5. Long-term Brightness:

7500 nit brightness capacity throughout product lifetime

SBO-P10 (Pitch 10mm outdoor full color)
Colour temperature	5000~9000 k
Pixel structure	Φ3 oval lamp, 1R1G1B
Pixel pitch	10mm
Pixel density	10, 000 dots/㎡
Luminance	7, 500cd/㎡
Module dimension	160mm(W) * 160mm(H)
Module resolution	16 pixel(W) * 16 pixel mm(H)
Cabinet dimension	1280 * 960mm
Cabinet resolution	128 * 96
Cabinet area	1.229 sq. meter
Optimal visual distance	>8m
Visual angel	110 / 50 degree (H/V)
Max power consumption	≤1200w / ㎡
Average power consumption	≤650w / ㎡
Brightness adjustment	Adjust according to the environment
Brightness adjustment	brightness software (0%-100%adjustable)
Gray scale	point by point 4096 gray grade levels of
Gray scale	each color, 16 bits γ correction available
Drive mode	1/4 dynamic scan, constant current
Frame frequency	≥60HZ
Refresh frequency	≥1000HZ
Input voltage	AC 90~260 volts
Operation temperature	﹣40℃~ +65℃
Operation humidity	10%~90%
Input signal	S-video, RF, RGB, Yuv, YC, composite…
Control system	DVI card + master control card + receiver card
MTBF	>5000 hrs
Life span (50% brightness)	100, 000 hrs
Malfunction dot rate	1/10000
Ingress protection rate (Front/ rear)	IP65 / IP54
Cabinet material	Epoxy paint coated, aluminum / iron
Application:	Rental / Permanent installation available
