Outdoor Fix Installation LED Display :P6.P8.P10(DIP).P10(SMD).P12.P16.P20.P25

Arise Technology Co., Ltd is a high-tech company dedicated in providing professional LED displays and comprehensive optoelectronic solutions.

Arise Technology owns strong execution, brilliant development strategies and programs, sustainable creation based on market demand. We spare no effort to provide customers with market-oriented innovative products with good reliability, suitable solutions and all-round service. Arise`s main products includes indoor and outdoor LED displays for fix installation, indoor and outdoor LED displays for rental business, stadium perimeter LED displays, and other special LED displays in accordance with customized requirements; LED display control system, related optoelectronic equipment, LED devices and components. We are ready to providing LED display solutions for oversea and domestic advertisement media, building advertising and lighting, municipal administration, hospital, hotel, bank, traffic, sports, entertainment, show, exhibition, etc.

We Arise Technology regards integrity in company staff, customers and suppliers as the enterprise foundations, market demands as the guide. We guarantee quality with profession and dedication and use enterprise culture to fill our brand. We keep striving, forging ahead, creating to provide customer with strong and unremitting support and backup.

Outdoor P6 LED Display Parameters
Model
FO-6
Parameters
Speci.
Pixel Pitch
6mm
Pixel Composition
1R1G1B
LED Type
3-in-1 SMD3535
Display brightness
7000cd/m² (adjustable)
Color Temperature
2500K to 10000K
Viewing Angle
H: 160°; V:160°
Pixel Density
27777 pixels/m²
Minimum Viewing Distance
≥6 M
Module Size
192mm×192mm.
Cabinet Size
W960mm×H960mm×D180mm
Cabinet Weight
46 kg/cabinet
Cabinet Size
0.9216 m²
Cabinet Material
Iron
Cabinet Aspect Ratio
1:1
Cabinet Resolution
160×160 pixels
Grey Scale
16bit(high refresh).14bit(common refresh)
Driving Mode
1/8 scan, constant current
Processing Depth
65536 scales
Colors
281.4 trillion
LED wave length
R: 620~630nm G: 520~535nm B: 465~475nm
Brightness Control
Manual/Automatic
Display contrast
5000:1
Frame Rate
50/60 Hz
Refresh Rate
3200 Hz(high refresh) .1000 Hz(common refresh)
Input Voltage
110~220VAC±15%
Input Power Frequency
50~60 Hz
Max. Power Consumption
830W/cabinet
Ave. Power Consumption
250W/cabinet
Life Span
≥100,000 hours
Input Signal
RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Communication Collection
CAT5 Cable: ≤140m;
Multi-mode fiber ≤ 500m; Single mode fiber ≤ 20km )
Installation Method
Hanging /wall mounted/other customized installation methods.
Protection Scale
IP65
Operation Humidity
0℃~+45℃/10~90%RH
Storage Humidity
-10℃~+55℃/10~90%RH
