Immersion Gold Single Layer Metal Core PCB MCPCB for LED Lighting

Descriptions:

COB MCPCB (known as "Chip-On-Board" metal core PCB) is a type of MCPCB used in thermoelectric separation application. By using COB MCPCB, the micro-chip (also known as “die") directly touches the metal core where the heat dissipate and electrically interconnect the trace of circuit board (wire-bonding) so that power supply can be provided.

Thermal Clad Metal Core PCB applications

• Power Conversion: Thermal clad PCB offers a variety of thermal performances, which is highly reliable and compatible with mechanical fasteners

• LEDs: Thermal clad PCB assures the lowest possible operating temperatures and maximum brightness, color and life.

• Motor Drives: Thermal clad PCB dielectric choices provide the electrical isolation meet operating parameters and safety agency test requirements.

• Solid State Relays: Thermal clad PCB offers a very thermally efficient and mechanically robust substrate.

• Automotive: The automotive industry uses thermal clad PCB boards as it needs long term reliability under high operating temperatures coupled with its requirement of effective space utilization.

Thermal Clad PCB Material

• Bergquist
• Thermagon
• Arlon
• Denka

Thermal Clad PCB Specifications

• 1 & 2 Layer Dielectrics
• Up to 6 oz finished Cu
• Aluminum, Copper and iron alloy base material up to .250" thick
• HASL, ENIG ,OSP, Pb Free HASL finishing available

Thermal Clad PCB Benefits

• Lower Operating Temperatures
• Improved Product Durability
• Increased Power Density
• Increased Thermal Efficiency
• Reduced Number of Interconnects
• Lower Junction Temperatures
• Reduced PCB Size
• Eliminates Older Hardware
• Minimizes Labor Required for Assembly
• Wide Variety of Form Factors
• Minimize Thermal Impedance

Thermal Clad Metal Core PCB fabrication contact us for more details.
