Custom Flate type graphic overlay with LED backlight
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| Transmission Rate | 10/100/1000Mbps |
|---|---|
| Voltage | 220V |
| Frequency | 50HZ-60HZ |
| Current Type | AC |
| Ports | 24 |
| Type | Slide Switches |
| Application | Industrial |
| Communication Mode | Full-Duplex & Half-Duplex |
| Function | Others |
Detail Description
Detailed Product Description
1.Flat keys with LED
2.100% function test
3.Life:>5milion times
4.waterproof
Keyboard switch is a conductive keypad panel with unique cosmetic design.
We offer full range designs of membrane keyboard switches:
Membrane switch with LED and EL backlight
Membrane switch with silicone rubber keypad
Tactile type membrane panel with LEDs
Membrane switch with EL plate
Membrane switch with tail termination either male or female connectors
Water-resistant type membrane switch
ITO touch screen embedded membrane switch
Membrane switch OEM orders are welcome
Flate type membrane keyboard with LED lights pecifications:
Electronic Characteristic |
<35V ( DC ) <100mA 1W |
Life Expectancy |
flat type ≥ 500 million times, tactile type: ≥ 100 million times |
Contact Resistance |
10Ω--500Ω (According the trace length and materials to confirm) |
Operation Temperature |
-40 °c ~ + 80 °c |
Insulating Impedance |
>100MΩ 250V DC |
Stock Temperature |
-40 °c ~ + 85 °c |
Resistance of the wire |
<1 Ω/cm width 1.27mm |
Humidity |
+ 40 °c 90 % ~ 95% 240 hour |
Operation Force |
flat type 57-284g (2-10 Oz), tactile type 170-397g (6-14 Oz) |
Switch stroke |
flat type 0.1-0.5mm, tactile type 0.6-1.5mm |
Custom Flate type graphic overlay with LED backlight Advantages:
1.Beautiful appearance, rich and bright in color, design can be arbitrary, the products can fully reflect the individual style of the product itself and designer.
2. Panel can wash, good protection of durable color, characters, logos and other panel contents without injury.
3. Small size, light weight, thin thickness, good tactility, abrasion resistant, installation and connection convenience.
4. Tightness is good, moisture-proof, dust-proof, waterproof, anti-oil, anti-corrosion and erosion of harmful gases proof, acid and alkali proof, quakeproof.
5. Low cost, high lifespan, membrane switches design and manufacture are using the keyboard as a whole way, whether on the material or mold charges, the costs are lowest, the life expectancy of different types of membrane switch is more than 100 million times.
6. Easy to operate, intuitive, safe and reliable, In-house 100% functionally tested, components are guaranteed without any intermittent problem.
7. Customized specification is available and keys can make different shapes.
Shenzhen Lunfeng Nameplate Co., Ltd. passed ISO9001: 2008 Quality System Certification
Good product + good service = Shenzhen Lunfeng Nameplate Co., Ltd.
Additional Information
| Payment Terms | T/T, L/C, Western Union |
|---|---|
| Minimum Order | 500pcs |
| Sample Available | YES |
| FOB Port | Shenzhen |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
