FLEX MEMBRANE SWITCHES

 Flex membrane switches are the most basic type of membrane switch we offer. As a less expensive alternative, our flex membrane switches feature excellent quality and outstanding performance. With a flex membrane switch, several design options are available for you to choose from, including:
Tactile & Non-Tactile Feedback
●Embossing
●Debossing
●Shielding
●Back-lighting
●LEDs


Characters of this product: with light weight, small size, service life is long, moistureproof, dustproof, resistance to drop, quake proof, vacuum forming touch type key, set the LED as one, it’s convenient to install.
Electronic property:
                Working voltage:≤50VDC
                Working current:≤100mA
                Contact resistance: 0.5～10Ω
                Loop resistance:≤50Ω
                Switch power: 0.25～500mW
                Insulation resistance:≥100MΩ（100VDC）
                Base material compression: 1500VDC
Characters of machine:
                Working life: 1 million times
                Operating force of the buttons: 15~750g
                Closed displacement: 0.1~0.4mm (no touch type), 0.4~1.0mm (touch type)
                Working temperature: -20℃~60℃, Storage temperature:-40℃~70℃
Operation humidity:≤95﹪
