full color LED display-outdoor

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

OEM/ODM	acceptable
Voltage	110-220V

Detail Description

		Specification of Outdoor LED Display
Items	P6.25	P8	P10	P12	P16	P20	P25
Pixel Pitch	6.25mm	8mm	10mm	12mm	16mm	20mm	25mm
Module Size	200*100mm	256*128	160×160mm	192*192mm	256*256mm	320*160mm	200*200mm
Pixel Density	25600dots/m2	15625dots/m2	10000dots/m2	6944dots/m2	3906dots/m2	2500dots/m2	1600dots/m2
Pixel Configuration	SMD 3in1	SMD 3in1	1R1G1B	1R1G1B	1R1G1B	2R1G1B	2R1G1B
LED Encapsulation	SMD3535	SMD3535	346	346	346	546	546
Module Resolution	32*16	32*16	16×16	16×16	16×16	16×8	8×8
Module Power Consumption	22W	22W	22W	22W	50W	25W	25W
Optimum Viewing Distance	6~20m	8~27m	10~33m	12~40m	16~53m	20~66m	25~83m
Optimum Viewing Angle	120°(H)/120°(V)	120°(H)/60°(V)
Max. Power Consumption	1320W/m2	1000W/m2	900W/m2	750W/m2	1050W/m2	750W/m2	630W/m2
Cabinet Size	800*800mm	768*768mm	960×960mm	960*960mm	1024×768mm	1280×960mm	1000×1000mm
Cabinet Resolution	128*128	96*96	96×96	80*80	64×48	64×48	40×40
Screen Weight	50KG/㎡	48KG/㎡	57KG/㎡	54KG/㎡	53KG/㎡	52KG/㎡	50KG/㎡
Driving Mode	1/4, constant	static, constant
Luminance of white balance	≥6500 Nits	≥6000 Nits	≥6500 Nits	≥6000 Nits	≥7000 Nits	≥5500 Nits	≥5000 Nits
Frame Frequency	≥60Hz/s
Refresh Rate	≥1000Hz/s
Operating Environment	Temperature, –30℃~+50℃; Humidity, 10%~90%RH
Ingress Protection	Front/Rear: IP65/IP43
Working Voltage	AC110V/220V ±10%
Grey Scale/Color	Displaying colors≥16.7M(synchronized)
Brightness Adjustment	256 levels of each color (manually), 8 levels of each color (automatically)
Input Signal	RF, S-Video, RGB, RGBHV, YUV, YC & Composition, etc.
Control System	PCTV non-linear editting card + DVI display card + main controller card + optic fiber transmission(Optional)
Control Distance	Cat5 cable, 100m; Multimode fiber, 500m; Monomode fiber, 10km
System Operating Platform	Windows 98 / 2000 / XP / Vista / 7, with a friendly User Interface, etc.
Aspect Ratio	4:3 (16:9 optional)
Defective Dot Rate	＜0.0001
MTBF	≥5000 hours
Lifespan	100,000 hours (50% brightness)

Additional Information

Payment Terms	T/T
Minimum Order	1 square meter
Lead Time / Delivery Time	15 Day(s)
Sample Available	YES
Delivery Details	according the request of the customer
FOB Port	Shenzhen
Loading Info	ocean or flight
Packing Info	plywood case or flight case
Target Market(s)	Africa(except Middle East), Eastern Europe, Japan & Korea, Mainland China, Middle East, Northern Europe, Central & Southern Asia, Southeast Asia
