full color LED display-indoor

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

OEM/ODM	acceptable
Voltage	110-220V

Detail Description

Items	P2.5	P3	P4	P5	P6	P7.62	P10
Pixel Pitch	2.5mm	3mm	4mm	5mm	6mm	7.62mm	10mm
Module Size	160*80mm	192*96mm	256×128mm	160×160mm	192×96mm	244×122mm	320×160mm
Pixel Density	160000dots/m2	111111dots/m2	62500dots/m2	40000dots/m2	27777dots/m2	17222dots/m2	10000dots/m2
Pixel Configuration	SMD 3in1	SMD 3in1	SMD 3in1	SMD 3in1	SMD 3in1	SMD 3in1	SMD 3in1
LED Encapsulation	SMD2121(black face)	SMD2121(black face)	SMD2121(black face)	SMD3528	SMD3528	SMD3528	SMD3528
Module Resolution	64×32	64×32	64×32	32×32	32×16	32×16	32×16
Module Power Consumption	18W	20W	20W	20W	20W	20W	20W
Optimum Viewing Distance	2~8	3~10	4~13m	5~16m	6~20m	7~25m	10~33m
Optimum Viewing Angle	120°(H)/120°(V)
Max. Power Consumption	1800W/m2	1500W/m2	1410W/m2	1050W/m2	1200W/m2	750W/m2	600W/m2
Cabinet Size	480×480mm	576×576mm	512×512mm	640×640mm	768×768mm	732×732 mm	960×960mm
Cabinet Resolution	192×192	192×192	128×128	128×128	128×128	96×96	96×96
Screen Weight	40KG/㎡	39KG/㎡	38KG/㎡	45KG/㎡	44KG/㎡	43KG/㎡	40KG/㎡
Driving Mode	1/16, constant	1/8, constant
Luminance of white balance	≥1200 Nits	≥1500 Nits	≥1500 Nits	≥1600 Nits	≥2000 Nits	≥1300 Nits	≥1200 Nits
Frame Frequency	≥60Hz/s
Refresh Rate	≥1000Hz/s
Operating Environment	Temperature, 0℃~+45℃; Humidity, 10%~90%RH
Ingress Protection	IP30
Working Voltage	AC110V/220V ±10%
Grey Scale/Color	Displaying colors≥16.7M(synchronized)
Brightness Adjustment	256 levels of each color (manually), 8 levels of each color (automatically)
Input Signal	RF, S-Video, RGB, RGBHV, YUV, YC & Composition, etc.
Control System	PCTV non-linear editting card + DVI display card + main controller card + optic fiber transmission(Optional)
Control Distance	Cat5 cable, 100m; Multimode fiber, 500m; Monomode fiber, 10km
System Operating Platform	Windows 98 / 2000 / XP / Vista / 7, with a friendly User Interface, etc.
Aspect Ratio	4:3 (16:9 optional)
Defective Dot Rate	＜0.0001
MTBF	≥5000 hours
Lifespan	100,000 hours (50% brightness)

Additional Information

Payment Terms	T/T
Minimum Order	1 square meter
Lead Time / Delivery Time	15 Day(s)
Sample Available	YES
Delivery Details	according the request of the customer
FOB Port	Shenzhen
Loading Info	ocean or flight
Packing Info	plywood case or flight case
Target Market(s)	Africa(except Middle East), Eastern Europe, Japan & Korea, Mainland China, Middle East, Northern Europe, Central & Southern Asia, Southeast Asia
