DIP Full-Color P16 Outdoor LED Display
Your message must be between 20 to 2000 characters
Contact NowBasic Specification
| Voltage | 110-220V |
|---|
Detail Description
| Specification Data for P16mm Outdoor LED Display | ||
| No. | Item | Specification |
| 1 | Pixel Pitch | PH16mm |
| 2 | LED Lamp | Silan (CREE optional) |
| 3 | LED Encapsulation & Pixel Configuration | DIP346 1R1G1B (first selection LEDs, to ensure color uniformity) |
| 4 | Pixel Density | 3906 dots/㎡ (uniformly spread over the surface, to ensure homogeneity) |
| 5 | Module Size / Pixel (W x H) | 256mmx256mm 16x16dots |
| 6 | Cabinet Size / Pixel (W x H) | 1024mmx768mm 64x48dots |
| 7 | Cabinet Type | steel, standard structure (aluminium, rental structure optional) |
| 8 | Screen Weight | 53KG/㎡ |
| 9 | Driver IC | MBI 5024 |
| 10 | Power Supply | Mean Well |
| 11 | Best View Distancing | 16~53m |
| 12 | Viewing Angle (H/V) | 120° / 60° (Standard LEDs Viewing Angle) |
| 13 | Brightness of White Balance | ≥7000 Nits (ensure brilliant image) |
| 14 | Brightness Adjustment | 256 levels of each color (manually), 8 levels of each color (automatically) |
| 15 | Grey Scale | DISplaying colors ≥16.7million (synchronized) |
| 16 | Operating Environment | Temperature, –30℃~+60℃; Humidity, 10%~90%RH |
| 17 | LEDs Lifetime | 100,000 Hours (50% brightness) |
| 18 | Working Voltage | AC110V/220V ±15% |
| 19 | Input Power Frequency Range | 50~60Hz |
| 20 | Screen Power Consumption | Max: 1050w/㎡; Avg: 450w/㎡ |
| 21 | Refresh Rate | ≥1000Hz |
| 22 | Frame Rate | ≥ 60Hz/s |
| 23 | Defective Dot Rate | ＜0.0001 |
| 24 | Ingress Protection (Front / Rear) | IP65 / IP43 |
| 25 | Aspect Ratio | 4:3 (16:9 optional) |
| 26 | Control System | Linsn controller card + DVI display card + function card (optional), etc. |
| 27 | Driving Mode | static, constant current |
| 28 | MTBF | ≥10000 hours |
| 29 | Color Temperature | 6500K±500 |
| 31 | Input Signal | RF, S-Video, RGB, RGBHV, YUV, YC & Composition, etc. |
| 32 | Signal Data Transfer Interface | RJ45, DVI, VGA, USB, RS232, RS485, etc. |
| 33 | Control Distance | cat5 cable, 100m; multimode fiber, 500m; monomode fiber, 10km |
| 34 | System Operating Platform | Windows 98 / 2000 / XP / Vista / 7, with a friendly User Interface, etc. |
| above parameter just for your reference,customizing can be acceptable |
Energy saving: Adopting the techniques of LED lamps with low driving current, adjustable brightness, efficient power supply with PFC, less heat dissipation, special cooling design, and appropriate power distribution from control system.
Cooling design: With special designs of separate driving ICs and LED lamps on the PCB, thermal radiator, air flow, ventilation and air conditioning, the LED display could keep working in an appropriate temperature.
Long life span: Benefiting from the techniques of energy saving design, high quality LED lamps, effective cooling design, adjustable brightness, all-round protection, and efficient power supply with PFC.
Protection: IP65 standard cabinets to protect LED display in extreme weathers; famous brand anti-lightning device to avoid lightning shock; the protective layer of our special conformal coating on PCB board to resist hostile environment.
Additional Information
| Payment Terms | T/T |
|---|---|
| Minimum Order | 1 square meter |
| Lead Time / Delivery Time | 15 Day(s) |
| Sample Available | YES |
| Delivery Details | Usually 15-25 working days according to order quantity and our stock. |
| Loading Info | Ocean or flight |
| Packing Info | Plywood case for free; or fright case at 120-150usd/pcs depending on the dimension. |
| Target Market(s) | Africa(except Middle East), Eastern Europe, Hong Kong/ Macao/ Taiwan, Japan & Korea, Latin America, Mainland China, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe |
