IP67 120W high bay with MeanWell driver, 80000h lifespan

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Product Description

Product Details

Basic Specification

Voltage	AC90-AC305V
Light Sourcing	60mil multi-chip
Grossweight	7.2kg
Flux	12000lumen
Lighting rate	110lumen/w
Voltage	220V
IP	IP65
Light Source	LED Lamp
Material	Acrylic, Aluminum, Copper, PC

Detail Description

5years warranty LED High Bay

Copper cooling system: working temp less than 60 celsius

Best LED in the world (60mil): 120-130lumen/watts

Meanwell LED driver: 5years warranty time AC90-305v

Different housing: 60 degree, 120 degree with both Aluminum, acrylic housing

Full color temp range, even with mixture color

Different size: 50w, 80w, 100w 150w 180w 200w 200w 250w 300w

ETL/CE (EMC, LVD)/RoHS/FCC/UL Approval

Isolated driver.Remote reach IP65 (water), users can be used drench side

Features

●  Light source: Epistar High Power LED
●  Low power consumption
●  High luminosity and long life time
●  Environmentally friendly
●  Excellent opto-electronic performance
●  Optimized heat fins for natural convection
●  High-efficiency cooling system
●  High-efficiency LED power driver
●  High light transmission PC protection cover

Light Source Test Report

Certificates

Typical Applications

●  Warehouse Lighting
●  Garage Lighting
●  Workshop Lighting
●  Public Lighting
●  Parking Lot Lighting
●  Walkway  Lighting
●  Other open spaces lighting

No.	1	2	3	4	5
Model No.	AMB-3L-50w	AMB-3L-80w	AMB-3L-100w	AMB-3L-120w	AMB-3L-150w
Power Consumptionb (W)	50	80	100	120	150
LED Initial Flux (LM)	5200	8300	12000	12500	15600
Lamp Flux (LM)	4800	7500	10400	11900	13500
Beam Angle	60°/120°/150°	60°/120°/150°	60°/120°/150°	60°/120°/150°	60°/120°/150°
Input Voltage (VAC)	90-305	90-305	90-305	90-305	90-305
Power Factor (PF)	>0.97	>0.97	>0.97	>0.97	>0.97
Power Efficiency	96%	96%	96%	96%	96%
Color	Warm White Cool White	Warm White Cool White	Warm White Cool White	Warm White Cool White	Warm White Cool White
Color Rendering Index (CRI)	Ra75-85	Ra75-85	Ra75-85	Ra75-85	Ra75-85
Working Enviornment	Temperature: -40℃～50℃ Humidity: 10%～90%	Temperature: -40℃～50℃ Humidity: 10%～90%	Temperature: -40℃～50℃ Humidity: 10%～90%	Temperature: -40℃～50℃ Humidity: 10%～90%	Temperature: -40℃～50℃ Humidity: 10%～90%
Material	Aluminum Copper PC	Aluminum Copper PC	Aluminum Copper PC	Aluminum Copper PC	Aluminum Copper PC
IP Rating	IP65	IP65	IP65	IP65	IP65
Working Life (Hours)	>80000	>80000	>80000	>80000	>80000
Product Dimension (mm)	60°: Φ390×280 120°: Φ415×356 150°: Φ580×280	60°: Φ480×525 120°: Φ580×415 150°: Φ580×320	60°: Φ480×525 120°: Φ580×415 150°: Φ580×320	60°: Φ480×565 120°: Φ580×455 150°: Φ580×360	60°: Φ480×565 120°: Φ580×455 150°: Φ580×360
Packing Dimension (mm)	Lamp Body 3kg/unit 2pcs/carton Reflector: 30pcs/carton 610×290×289	Lamp Body 5.5kg/unit 2pcs/carton Reflector: 30pcs/carton 610×310×429	Lamp Body 5.9kg/unit 2pcs/carton Reflector: 30pcs/carton 610×310×429	Lamp Body 7.2kg/unit 2pcs/carton Reflector: 30pcs/carton 610×310×610	Lamp Body 7.5kg/unit 2pcs/carton Reflector: 30pcs/carton 610×310×610
Net Weight/GrossWeight (Kgs)	3kg/3.5kg	5.5kg/6kg	5.9kg/6.5kg	7.2kg/8kg	7.5k/8kg

Notes:
1. 60 or 120-degree angle of projection edges of different heights
2. Test environment:
Room temperature 30 degrees
Humidity: 70%
Voltage: AC65-305V 50Hz

WHY AMB?

1. Manufaturer -competive price and good qulity, and well-known after-sale service!
2. Experienced technical staff, advanced equipment, experienced R&D dept.
3. OEM/ODM accepted, clients\' special requirement accepted
4. Large scale production lines, strong production capability
5. Unique design, No matter what product and solution you need, just give us your emails or calls,

6. Our dedicated sales and tech support team will be happly to hear from you.
7. Guarantee/Warranty: 3 or 5year.
8. Our Product/Service: LED Fluorescent tubes, LED Light Strips, LED Bulbs, LED Lamps, LED

Modules, LED street light, LED Light Bars, LED Floodlight, LED Wall Lamp, LED Controllers, LED

Spotlights, LED DownLight, and related accessories.

Our promises

       1. High quality,  competetive price and considerate service
       2. Streamline the buying and paying processes, Easy business.
       3. Door to door delivery with speed and precision all over the world  .
       4. Professional, Experienced Ensure the excellent quality of our products

Payment terms：

L/C, T/T, Western Union, Paypal ect.

Packing & Delivery：
1. Packing: Standard cartoon or Packing as customer’s requirement
2. Delivery Time: within 7 working days for samples, 15 workdays for big order

Shipping options：
        1. By express: Such as DHL,UPS, TNT, FEDEX ect.
        2. Air Freight:When you order moer than 100kg which will be more economical than express
        3. Sea freight: Shipping by SEA is available after customer provide destination port.
        4. Agent designated by client: Please tell us the contact details of your shipping agent/forwarder.

Installation:

package:

Additional Information

Payment Terms	T/T, L/C, Western Union, Others
Minimum Order	2PCS
Lead Time / Delivery Time	15 Day(s)
Sample Available	YES
Delivery Details	7-15 days after reciving the payment
FOB Port	Shenzhen
Loading Info	Bulk order By sea .samples order by air .
Packing Info	2pcs / carton
Target Market(s)	Africa(except Middle East), Eastern Europe, Japan & Korea, Latin America, Middle East, North America, Northern Europe, Oceania, Central & Southern Asia, Southeast Asia, Western & Southern Europe
