Waterproof Strip LED Curtain Display Screen for Media Facades SMD5050 P25 1R1G1B 300W/m2
Applications:
Based on its high cost efficiency, we suggest customers to use P25 strip LED screen mainly for:
1) LED media facades
2) LED backdrop
3) Vocal concert
Description:
P25 strip LED screen uses SMD5050 LEDs, SMD5050 is one kind of new SMD series LEDs, it has been proved to be much more brightness, and good waterproof.
Aluminum cabinets with high-end technology, ensure save energy and long life span.
Fast locks and hang up poles make the installation and dismantling easy job. Also we use flight cases for packing of
cabinets and accessories which enable customers to move the LED wall anywhere conveniently.
Specifications:
|
Catalog |
UC-IF-P25S |
|
LED encapsulation |
3 in 1 |
|
LED lamp type |
SMD3528 |
|
Pixel pitch |
25 |
|
Module size |
8 x 600 (mm *mm) |
|
Module resolution |
1 x 24 |
|
Cabinet type |
common cabinet |
|
Pixel configuration |
1R1G1B |
|
Pixel density |
10000 (dot/m2) |
|
Best viewing angle |
H: 140° V: 140° |
|
Max.power consumption |
300W/m2 |
|
Frame change frequency |
60Hz/s |
|
Refresh rate |
180Hz~1600Hz |
|
Luminance |
1500cd/ m2 (1/8) |
|
Driving mode |
1/8 Scan constant current |
|
Working voltage |
AC 220V/ 50Hz or 100V / 50Hz |
|
Working environment |
Temperature: -10℃ ~ 50℃, Related humidity: 10% ~ 90% |
|
Grey scale / color |
8192 grades for R, G and B, Display ≥549 billion colors (synchronized) |
|
Brightness adjustment |
(Manual adjustment: 1024 levels) (Automatic adjustment: 8 grades) |
|
Control system |
Synchronous / off-line control system; Network Cable or optical fiber transmission |
|
MTBF |
10000 hours |
|
Life-span |
50000 hours |
