RF Power Transistors MRF9120 - Motorola, Inc - RF Power Fie

Quick Detail:

MRF9120 - Motorola, Inc - RF Power Field Effect Transistors

Description:

Designed for broadband commercial and industrial applications with frequen-
cies from 865 to 895 MHz. The high gain and broadband performance of these
devices make them ideal for large-signal, common source amplifier applications
in 26 volt base station equipment.


Applications:

• Typical CDMA Performance @ 880 MHz, 26 Volts, IDQ = 2 x 500 mA
IS-97 CDMA Pilot, Sync, Paging, Traffic Codes 8 Through 13
Output Power — 26 Watts
Power Gain — 16 dB
Efficiency — 26%
Adjacent Channel Power —
750 kHz: -45 dBc @ 30 kHz BW
1.98 MHz: -60 dBc @ 30 kHz BW
• Capable of Handling 10:1 VSWR, @ 26 Vdc, 880 MHz, 120 Watts (CW)
Output Power
• Characterized with Series Equivalent Large-Signal Impedance Parameters
• Integrated ESD Protection
• Designed for Maximum Gain and Insertion Phase Flatness
• Excellent Thermal Stability
• Available with Low Gold Plating Thickness on Leads. L Suffix Indicates
40µ″ Nominal.
• In Tape and Reel. R3 Suffix = 250 Units per 56 mm, 13 inch Reel
