High current slip rings

DTS-65X3P360 slip rings is designed for passing 3 ways 360A current in one body,of which the current was lead out by copper strip from stator side and rotor side. The shaft of slip rings is made by heat-resisting plastic. Copper alloy material leads a reliable contact. This kind of slip ring is designed for 60RPM, based on good thermal design & heat-resisting materials.
A. Feature:
1) One-piece shaft design;
2) Copper alloy contact materials;
3) Separated design;
4) High operating speed;
5) Fit for use in the working condition of high temperature.

B. Technical specification:

Channels : 3 rings(for signal)
Operation Voltage: 0~380VAC/DC
Current: 360A/Ring
Operate Speed: 60RPM
Contact material: Precious Metal
Operate temperature: -30~240℃
Electric noise: Max.40m Ω
Dielectric strength: 500VAC@50Hz,60s
Insulation resistance: 500MΩ @600VDC

C. Application:
● Rotary tables, test equipment;
● Plating line;
● High-power system;
● Cable reels.

D. Option:
●Higher voltage and current capacity;
●Higher speed;
●wider range of temperature;
●Higher protection class;
●style of exits for lead wires;
●Flange for installation.
