10600nm filter Fractional CO2 Laser Stretch Mark Laser Beau

Model Number

COP-01 –10600 fractional CO2 laser with CE

Application Range

1. Various wrinkles (forehead wrinles, frown lines, crow's-feet, wrinkles around mouth, cervical stripe, Stretch marks, etc.).

2. Skin sagging, pouch, acne dent

3. Various scars (trauma scar, burned scar, suture scar)

4. Color patch, ichthyosis, borsten, vascular veins, etc.

System Parameter

laser wavelength

10.6μm±0.1μm

Output power

1-30W

simmer voltage

≤25kV

working voltage

≤15kV

Focusing diameter

≤0.5mm

Direct beam of lightgreen semiconductor laser532nm

≤5mW
conduct system7 joimted arms to conduct light

working styleGalvanometer scan (Lattice)

scan area20×20mm

scan Shape

rectangle, circle, oval

scan speed

10m/s

pulse space

0-999ms

input power

450VA

smoke eliminate system

Inside have

cooling systemwater circulation system

water + air press

environment temperature relative

5~40

Humidity propority

≤80

Feather

1. Sealed-off CO 2 laser technology
2. CW, Pulse and Super Pulse Operation Modes
3. Thin Film Key Switch, Microprocessor Controlled
4. Alphanumeric Message Display
5. 7-joint spring balanced articulated arm
6. Pilot Beam Of Diode Laser
7. Safety Protection with automatic alarm

Treatment principles

Fractional laser therapy use laser to make tiny pore on skin, then cause a chain of biochemical reactions, finally achieve the result of skin tightening, skin rejuvenation and speckle removal. The fractional laser only cover part of skin tissue and pore made by laser do not overlap, so the normal skin can be remained and recover quickly. The therapy is safe and can be used on any parts of body. Curative effect is very evident and well confirmed.

It is approved that comparing with non-ablasive laser, CO2 laser (ablasive) can achieve quick effect while reducing Post-inflammatory Hyperpigmentation, and it can remove the speckles directly. CO2 laser can penetrate just enough to dermis and vaporize pigment, meanwhile heat is guide to superficial layer of dermis to tightening skin and stimulate regeneration of collagen
