Blue Floor Standing Internet Bill Payment Kiosk Touchscreen

Get Latest Price

Min. Order:: 1

Min. Order:: 1

Delivery Time:: 30 Days

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	SHENZHEN, CHINA

Product Description

Blue Floor Standing Internet Bill Payment Kiosk Touchscreen For Bank

Quick Detail:

Self service security payment terminal for multi payment solutions via cash, coins, bank card or check etc…
Interactive touch technology;
Unattended, Anti vandalism, strong metal or stainless steel mechanism integrated with smart electronic alarming and server system.
More than 15 years manufacturing experiences and products applied /placed more than 180 countries
Upgradable functions available
Flexible Modification to fit customers requirements
In-door or out-door optional

Description:

KMY8800 series kiosks are ATM machine, KMY ATMs are especially designed for banking and retailing for the cash dispensing and recycling. It’s flexible design and high quality performance can bring “low cost, high reliability and stability” in your ATM investment.

Specifications:

KMY Bill Payment Kiosk Hardware Solution
Components	Specification
Computer	Industrial PC or Standard PC upon request Support variable processors, Supports Intel Core™ i7/i5/i3 processor, Intel Core 2 Duo, Intel Pentium Dual-Core, Intel Pentium 4, Intel ATOM series, Intel Celeron, etc. Min 2G RAM, Min 250HDD, or SDD flexible. Supports serial ports and USB ports for satisfying different devices connection Industrial Power supply; Graphics integrated Wireless or Ethernet collection available.
Monitor	A+ class TFT-LCD Monitor: 15, 17 , 19, 21, 22, or bigger size or smaller size available.
Touch screen	SAW touch /Infrad touch / Capacitive touch//5 wire resistive touch against different kiosk project requirements.
Cash Acceptor	Note/Coin acceptor with high validation rate >98%; Currencies and denominations, bill width and cashbox capacity dependable on different project requirements; Single note or bulknote acceptor optional; RS232 or USB interface
Cash Dispenser	Note/Coin dispenser; Currencies and denominations, cassette capacity dependable on different project requirements; Dispensing speed: 4 notes/sec, 2~4 coins/sec; RS232 or USB interface
Payment Module/POS	EMV certified Chip & PIN PCI PED 3x compliance
Printer	Thermal Printer : Width 80mm~210mm; black mark sensor; full/half cutter
Speaker	Multimedia : Left-right bi-channel amplified output
Enclosure	Moistureproof, Antirust, Anti-acid, Anti-dust, Static free High quality steel sheet made enclosure/ stainless steel / Aluminum available. Powder coated finish; color to be negotiated with customer.
OS& Drivers	Windows XP/Window7/Unix/Linux OS available; All related hardware drivers/SDK available for the software development/integration
Packing	Bubble Foam, carton, wooden case
Other Optional : UPS, Video Camera, Alarm System, Barcode Scanner, Track Ball, Photo Printer, Cash Acceptor, Card Dispenser, Check Acceptor, Infrared, Bluetooth, PSAM Card, etc.
