HDMI Matrix 4 x 4, 4*2K and HDMI 1.4, 12V DC, 2.5A Power Supply

HDMI Matrix 4 x 4, 4*2K and HDMI 1.4, 12V DC, 2.5A Power Supply

Get Latest Price

Payment Type:: T/T, L/C at Sight or PayPal

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T, L/C at Sight or PayPal

Product Description

Introduction:

HDM-944 is a 4-by-4 DVI/HDMI matrix supporting output resolution up to 4K x 2K
It allows any source (Blu-ray player, HD DVD player, satellite receiver, game system) to be shown on any of four displays simultaneously, no matter the source is HDCP encryption or not
Extra infrared receiver port is supplied for remote control
HDM-944 offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and projector factory, data center control, information distribution, conference room presentation, school and corporate training environments

Features:

Supports display resolutions up to 4K x 2K at 30Hz, 1,080P at 120Hz and 1,080P 3D at 60Hz
3D HDMI 1.4a video format supported
3D video support including frame packing for all 3D formats up to a 297MHz TMDS clock
Supports deep color up to 48-bit per pixel
HDCP 1.4 support (input), HDCP v1.4a protocol compliant (output)
Supports reception of any audio data conforming to the HDMI specification 1.4 such ad L-PCM at up to 192kHz, compressed audio (IEC 61937), DSD, DST, DTS and HBR
Full colorimetric including sYCC601, adobe RGB, adobe YCC601, xvYCC extended gamut color
Operating for TMDS clock frequency up to 300MHz

Packaging:

HDMI matrix: 1 piece
Adapter: 1 piece
Operating manual: 1 piece
Remote controller: 1 piece

Specifications:

Frequency bandwidth: 2.97Gbps
Input ports: 4 x HDMI female input ports
Output ports: 4 x HDMI female output ports
Power supply: 12V DC, 2.5A
ESD protection human body model: ± 8kV (air-gap discharge) ± 4kV (contact discharge)
Dimensions (W x D x H): 113 X 260 X 26mm
Weight: 750g

HDM-944 is a 4-by-4 DVI/HDMI matrix supporting output resolution up to 4K x 2K

It allows any source (Blu-ray player, HD DVD player, satellite receiver, game system) to be shown on any of four displays simultaneously, no matter the source is HDCP encryption or not

Extra infrared receiver port is supplied for remote control

HDM-944 offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and projector factory, data center control, information distribution, conference room presentation, school and corporate training environments

Supports display resolutions up to 4K x 2K at 30Hz, 1,080P at 120Hz and 1,080P 3D at 60Hz

3D HDMI 1.4a video format supported

3D video support including frame packing for all 3D formats up to a 297MHz TMDS clock

Supports deep color up to 48-bit per pixel

HDCP 1.4 support (input), HDCP v1.4a protocol compliant (output)

Supports reception of any audio data conforming to the HDMI specification 1.4 such ad L-PCM at up to 192kHz, compressed audio (IEC 61937), DSD, DST, DTS and HBR

Full colorimetric including sYCC601, adobe RGB, adobe YCC601, xvYCC extended gamut color

Operating for TMDS clock frequency up to 300MHz

HDMI matrix: 1 piece

Adapter: 1 piece

Operating manual: 1 piece

Remote controller: 1 piece

Frequency bandwidth: 2.97Gbps

Input ports: 4 x HDMI female input ports

Output ports: 4 x HDMI female output ports

Power supply: 12V DC, 2.5A

ESD protection human body model: ± 8kV (air-gap discharge) ± 4kV (contact discharge)

Dimensions (W x D x H): 113 X 260 X 26mm
