HDMI Extender, Over One Cat6, Bandwidth Up to 225MHz, 5-12V DC Wide Power Supply

HDMI Extender, Over One Cat6, Bandwidth Up to 225MHz, 5-12V DC Wide Power Supply

Get Latest Price

Payment Type:: T/T or L/C at Sight

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	T/T or L/C at Sight

Product Description

Introduction:

The HDMI extender over one Cat6 is a tool for extending your HDMI signal over long distances to a compatible display
Instead of using expensive HDMI cables, your existing Cat6 cables/sockets can be utilized to perform advanced functions like transferring deep color (12 bits/color) video and digital audio, with a bandwidth up to 225MHz
The HDMI extender and receiver, over one Cat6 extender is your substantial HDMI extender tool
The HDMI extender over one Cat6 also support IR re-transmitting, so you can control the source which is 100 meters outside using the HDMI extender

Features

5-12V DC wide power supply
HDMI 1.3, HDCP 1.1 and DVI1.1 compliant
HDMI definition 1,080P/1080i/720P/576P/576i/480P/480i at 24/50/60fps
Support deep color up to 12 bits/color
Support IR re-transmitting
Uses one Cat6 cable for data/DDC transmission
Equalizes and recovers incoming TMDS data before re-transmitting it in optimal quality regardless of the incoming signal quality
Cable testing showed that with 1,080P resolution the HDMI input source can be 20 meters away
When transmitting a signal in 1,080P resolution the Cat6 operating distance is 100 meters

Specifications:

Frequency bandwidth 2.25Gbps (single link)
HDMI transmitter input/output ports 1x HDMI female port/1 x Cat6
HDMI receiver input/output ports 1 x HDMI female port/1 x Cat6
Power supply: 5-12V DC
ESD protection human body model: ±8kV (air-gap discharge)
±4kV (contact discharge)
Dimensions (WxDxH): 65 x 100 x 25mm
Chassis material: aluminum
Operating temperature: 0 - 40˚C/32 - 104˚F
Storage temperature: -20 - 60˚C/-4 - 140˚F
Relative humidity: 20-90% RH (non-condensing)

The HDMI extender over one Cat6 is a tool for extending your HDMI signal over long distances to a compatible display

Instead of using expensive HDMI cables, your existing Cat6 cables/sockets can be utilized to perform advanced functions like transferring deep color (12 bits/color) video and digital audio, with a bandwidth up to 225MHz

The HDMI extender and receiver, over one Cat6 extender is your substantial HDMI extender tool

The HDMI extender over one Cat6 also support IR re-transmitting, so you can control the source which is 100 meters outside using the HDMI extender

5-12V DC wide power supply

HDMI 1.3, HDCP 1.1 and DVI1.1 compliant

HDMI definition 1,080P/1080i/720P/576P/576i/480P/480i at 24/50/60fps

Support deep color up to 12 bits/color

Support IR re-transmitting

Uses one Cat6 cable for data/DDC transmission

Equalizes and recovers incoming TMDS data before re-transmitting it in optimal quality regardless of the incoming signal quality

Cable testing showed that with 1,080P resolution the HDMI input source can be 20 meters away

When transmitting a signal in 1,080P resolution the Cat6 operating distance is 100 meters

Frequency bandwidth 2.25Gbps (single link)
