Product Description

Overview:

Designed to help photographers or film makers to get better focus and thus better pictures and videos with video cameras
Presents crystal clear image of what you are shooting directly onto a large 800 x 480 LCD screen, meaning you never have to strain your eyes to see any image again
Ideal for armatures as well as professionals who need to view images all day long
Excellent menu design, custom preset button, knob-control mechanism, unique sun-hood and battery plate
Users can scroll up and down easily to view the menu confirmation, customize regularly-used function to 6 buttons

Specifications:

Size: 5 inches
Resolutions: 800 x 480P
Pixel pitch: 0.045 x 0.135mm
Color depth: 16.7M (8 bits)
Viewing angles: 120/140 degrees
Luminance of white: 350 cd/㎡ (center)
Contrast ratio: 500:1
Display area: 108 (H) x 64.8mm (V)
Input/output connector: 1x HDMI input, 1x HDMI output (optional)
Input signals: HDMI 480i/480p/720p/1080i/1080p
Output signals: HDMI 480i/480p/720p/1080i/1080p
Audio out: Analog stereo (phone jack) internal speaker (mixed mono)
Powers: DC 6-20V
Power consumption (approx): 4.5W (typical)
Operating temperatures: 0 to 45℃ (32 to 113℉)
Storage temperatures: -20 to 60℃ (14 to 140℉)
Main body dimensions (mm/inches): 148 x 105 x 50 (5.82 x 4.13 x 1.97)
Weights: 0.39/0.86lbs

Accessories:

Field monitor with sun-hood (detachable)
AC adapter
User manual
F fey cable control
Shoe mount adaptor
Screws (for fixing the battery plate more tightly)
HDMI cable
Battery plate-LP-E6
Battery plate-F970 (optional)
Battery-D28S (optional)
Carry bag

Designed to help photographers or film makers to get better focus and thus better pictures and videos with video cameras

Presents crystal clear image of what you are shooting directly onto a large 800 x 480 LCD screen, meaning you never have to strain your eyes to see any image again

Ideal for armatures as well as professionals who need to view images all day long

Excellent menu design, custom preset button, knob-control mechanism, unique sun-hood and battery plate

Users can scroll up and down easily to view the menu confirmation, customize regularly-used function to 6 buttons

Size: 5 inches

Resolutions: 800 x 480P

Pixel pitch: 0.045 x 0.135mm

Color depth: 16.7M (8 bits)

Viewing angles: 120/140 degrees

Luminance of white: 350 cd/㎡ (center)

Contrast ratio: 500:1

Display area: 108 (H) x 64.8mm (V)

Input/output connector: 1x HDMI input, 1x HDMI output (optional)
