2mm Tower Type Yellow Green LED Indicator, 5V Reverse Voltage

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Payment Type:	Telegraphic Transfer in Advance (Advance TT, T/T)

Product Description

Features:

Description:

Parameters:

Power dissipation: 78mW

Peak forward current (1/10 duty cycle, 0.1ms pulse width):100mA

Continuous forward current: 30mA

Reverse voltage: 5V

Operating temperature range: -40 to +85

Storage temperature range: -40 to +100

Lead soldering temperature: 260 for 5 seconds

Luminous intensity: 1-6 mcd (IF=10mA)

Viewing angle: 70 degrees

Peak emission wavelength: 565nm (IF=20mA)

Dominant wavelength: 570nm (IF=20mA)

Spectrum radiation bandwidth: 30nm (IF=20mA)

Forward voltage: 1.60, 2.20, 2.60V (IF=20mA)

Reverse current IR: 10¼A (VR=5)

2mm tower

High-efficiency

Selected minimum intensities

Available on tape and reel

The product itself will remain within RoHS compliantversion

Specially designed for applications requiring higherbrightness

Available with different colors, intensities

Applications:

Status indicators

Commercial use

Advertising signs

Back lighting

Specifications:

Chip material: GaP

Lens color: green diffused
